FEATURES:INPUT SECTION MONO CHANNELS• 4 mono inputs with gold plated XLR and balanced TRS jack
• Mic / line inputs with TRIM, 48V Phantom Power and low cut filter @75Hz - 18dB / Oct.
• EQ: 3 - band fixed EQ
MONO / STEREO CHANNEL• MIC input with TRIM, 48V Phantom
• Two line inputs with 2 TRS balanced input jacks, mono on left jack only
• 3 - band fixed EQ
STEREO CHANNELS• 2 TRS balanced input jacks each channel, mono on left jack only, with GAIN switch
• 2 stereo channel with 3 - band EQ
COMMON FEATURES FOR ALL INPUT CHANNELS• 2 AUX sends:
AUX 1 PRE - FADER, for monitoring
AUX 2 POST - FADER, for effects sends
• Peak LED on each input channel
MASTER SECTION• 2 Stereo AUX return with level and routing to AUX 1
• 2 - track IN / OUT with level and discrete switches for routing to Control Room and to Main Mix
• 24 - bit internal DSP with 256 effects (16 presets by 16 variations), DSP MUTE and Peak LED.
ANALOGUE INSERTS & OUTPUTS• 4 insert (mono channels) MAIN MIX outputs
USB SECTION• Recording / overdubbing can be achieved by selecting input channels 1 - 2 or L R MAIN MIX output signals
• Playback can be achieved by selecting MAIN MIX or HIGHER NUMBERED stereo channel (CH7/8)
• By selecting the HIGHER NUMBERED stereo channel you can easily adjust the desired monitoring & fx levels for each overdubbing musician
• Dimensions (WxDxH) and Weight
(10.6" x 12.2" x 1.4"/1.8"); 3.0Kg (6.6 lb)
