Alto Professional RADIUS100L Wireless Lavalier System

Not In Stock Not In Stock, But We'll Order It In For You
This item is not in stock, but can usually be back in our warehouse within 4 to 10 days, depending upon stock levels at Alto Professional's warehouse. This time frame is not guaranteed, rather an estimate based on historical data. Order now! We'll notify you promptly if we hear of any delay.
Free Shipping FREE Ground Shipping to the contiguous U.S. (details)
Affirm Financing
Future Pay
    • Buy Now and Earn 398 PDJ Bucks ($3.98)! Applies only to registered, domestic U.S. customers. Exact value may vary once logged in.
Radius 100L wireless lavalier microphone is an easy-to-use UHF diversity wireless microphone system that provides reliable, crystal-clear sound for a wide range of professional vocal applications. Alto's switching diversity receiver design utilizes two separate antenna systems for uncompromised wireless performance. If one antenna experiences signal interruption, the receiver instantly switches to the second antenna. This assures you of an extremely stable, reliable wireless signal,with virtually no chance of dropout or interruption. This is the promise of wireless performance-delivered!

• All-in-one, easy-to-use wireless microphone system for professional vocal applications
• Dual-antenna UHF diversity receiver for increased reliability and signal consistency
• UHF band operation (520 - 937.5MHz) regionally selected
• Receiver includes a high-visibility back-lit LCD display: Displays RF frequency and channel, AF and RF signal levels and other critical functions
• High-quality lavalier/lapel microphone with included clip
• Wireless belt-pack transmitter
• Single-button scan feature for quickly identifying the optimal operating frequency
• Sync function automatically synchronizes transmitter and receiver frequency
• Squelch control for maximum clarity and dynamic range
• Front-panel rotary volume control
• Balanced XLR and unbalanced -inch mic or line-level output

• UHF Band Operation: 520937.5 MHz (region-specific)
• Oscillator: PLL Synthesized
• Frequency Stability: 0.005%
• Modulation: FM
• Transmission Range: 328 feet / 100 meters
• Signal-to-Noise Ratio: > 100 dB (at 20 KHz deviation and 60 dBV antenna input
• Image & Spurious Rejection: 80 dB minimum
• Receiving Sensitivity: At 3 uV over 52 dB/A SNR
• Selectivity: > 50 dB
• AF Response: 80 Hz 18 KHz
• THD: < 1% (at 1 KHz)
• IF Frequency: 1st: 243.95 MHz / 2nd: 10.7 MHz
• Dynamic Range: > 100 dB
• Tone Signal: 32.768 KHz
• Audio Output: 1 balanced XLR1 unbalanced 1/4" (6.35mm)
• Display: High-visibility back-lit LCD with RF and AF meters
• Power: Supply: 12 V, 1 A, center positive (adapter included)Consumption: 150 mA 10 mA
• Case: Half 19" EIA-rack plastic case
• Dimensions: 7.9" x 4.8" x 1.7"20.0 cm x 12.2 cm x 4.2 cm
• Weight: 2.1 lbs.1.0 kg

• UHF Band Operation: 520937.5 MHz (region-specific)
• Channel Selection: Synchronization with receiver
• RF Power Output: 10 mW (maximum)
• Deviation: 20 KHz with limiting compressor
• Spurious Emission: > 60 dB below carrier frequency
• Display: Belt-Pack Transmitter:2-digit 7-segment LCD2-digit 7-segment LCD
• Power: Belt-Pack Transmitter: Consumption:2.4 VDC (1.2V via 2 AA batteries)3 VDC (1.5V via 2 AA batteries)120 mA 10 mA
• Dimensions:Belt-Pack Transmitter: 2.6" x 3.8" x 0.9" / 6.5 cm x 9.7 cm x 2.4 cm
• Weights: Belt-Pack Transmitter: 0.2 lbs. / 0.1 kg
