Alto REVO SUB118P 18" Passive Vented Subwoofer

alto revosub118
alto revosub118 Alto REVO SUB118P 18" Passive Vented Subwoofer
Images may show accessories or configurations not packaged with this item.

Be the first to review this product

Unavailable Discontinued or no longer available.
Sorry, this item is discontinued or no longer available from us. We've left this page up for reference only. Check out some of the other great alternatives on this page or click below to see if it can still be found elsewhere.
Buy on Amazon
The REVO SUB118P is a vented subwoofer equipped with a single custom high power 18" subwoofer with 4" high-power sandwich copper voice coil on fiberglass former, double spider, ceramic magnet, and weather resistant cone. The enclosure is made with a 18mm multi-layer plywood, finished with anti-scratch black paint, with a strong perforated metal grille, two metal handles, one pole socket for satellite and four wheels.

• Operating Frequency Range: 37Hz-200Hz (|10dB)
• Frequency Response: 43Hz-200Hz ({/| 3dB)
• Nominal SPL @ 1m: 122dB SPL Continuous (Direct Mode)
• Maximum SPL @ 1m: 125dB Peak (Direct Mode)
• Power Rating (Direct Mode): 750W RMS/1500W Peak (AES Standard)
• Transducers Low: 18" Subwoofer, 4" high-power voice coil ceramic magnet, weather resistant cone.
• Crossover modes: Passive, Direct with externally selector in direct connection
• System Sensitivity (1w@ 1 mt): 97dB SPL, passive version
• Nominal Impedance: 8O (nominal)
• Suspension/Mounting: Single 36mm pole socket, four integrated point for line array suspension, two handle, our optional wheel
• Enclosure: 18mm calibrated plywood, black finish, perforated metal grille, silver finish.
• Input Connectors: Two SPK N-L 4 type, Passive
• Dimensions (HWD): 620 620 700mm (24.4" 24.4" 27.5")
• Weight: 51.8kg (114.2 lb)

Additional Information

ManufacturerAlto Professional
Product ConditionNew - On Clearance
