SO MANY EFFECTS, SO LITTLE TIMEThe TMX80DFX's on-board Alesis digital effects processor provides pristine 24-bit, ultra-clean digital effects you, and the audience, won't soon forget. Effects include Echo, Echo+Verb, Tremolo, Plate, Chorus, Vocal, Rotary, Small Room, Flange Verb, Large Hall. 100 Presets are included, leaving you plenty of options for coloring the mix.
POWER TO SPAREDid we mention power? The TMX80DFX comes standard with the ability to deliver ultra-clean power at 2 x 350W (4-ohms) or 2 x 180W (8-ohms). These aren't peak rating either, this is pure continuous power. In short, it's a workhorse. Fortunately, all that power isn't as heavy as you might expect. Weighing in at just under 11 pounds, the TMX80DFX is a clear winner in the power-to-weight class.
TECH INFORMATIONInput ChannelsMono channels: (Ch. 1 - Ch. 4)
Microphone Input: Electronically Balanced, discrete input configuration
Frequency Response: 20 Hz to 22 kHz, +/-1 dB
Distortion: (THD&N) ?0.005% At + 4 dBu, 1 kHz
Gain range: 0 dB to 50 dB (Mic)
Maximum Voltage Gain 70 dB Ch. Mic input - Main Mix Out & Tape Out
80 dB Ch. Mic input - Control Room & Phones
60 dB Ch. Mic input - Aux Send
SNR (Signal to Noise Ratio): ?110 dBu
Phantom power (Mic Pin2/Pin3 And Pin1): +45 V +49 V with switch control
Line Input Electronically Balanced (SW to LINE)
Frequency Response: 20 Hz to 22 kHz, +/-1 dB
Distortion: (THD&N) ?0.005% at +4 dBu, 1 kHz
Gain range: 15 dBu to 35 dBu
Stereo channels: (Ch. 5 - 8)
Line Input: Electronically Balanced (SW to Line)
SNR: (Signal-to-Noise Rate ) ?110 dBu
Frequency Response: 20 Hz to 22 kHz, +/-1 dB
Distortion: (THD&N) ?0.005% At + 4dBu, 1 kHz
Gain range: -20 dBu to +20 dBu
60 dB Ch. Line ? Min Mix out
Maximum Voltage Gain
20 dB FX Return?Main Mix Out
20 dB RCA Tape Input?Main Mix Out
Impedance Microphone Input: 3.9 kOhms
All Other Input: 10 kOhms or Greater
Tape Out: 1 kOhms
All Other Outputs: 120 Ohms
Equalization Mono channels
High 15 dB @ 12 kHz
Mid 15 dB @ 2.5 kHz
Low 15 dB @ 80 Hz
Stereo channels
High 15 dB @ 12 kHz
Mid 15 dB @ 2.5 kHz
Low 15 dB @ 80 Hz
Stereo Graphic EQ
12 dB @ 16 kHz
12 dB @ 8 kHz
12 dB @ 4 kHz
12 dB @ 2 kHz
12 dB @ 1 kHz
12 dB @ 500 Hz
12 dB @ 250 Hz
12 dB @ 125 Hz
12 dB @ 63 Hz
DSP Section A/D and D/A Converters: 24-bit
DSP Resolution: 24-bit
Type of effects: Echo, Echo + Verb, Tremolo, Plate, Chorus, Vocal, Rotary, Small Room, Flange Verb, Large Hall
Presets: 100
Controls: 100-position preset selector
Clip LED
Mute Switch
Foot Switch with LED indicator
Crosstalk Adjacent Input: ?-80 dB @ 1KHz (CH1-6)
Input to Output: ?-75 dB @ 1KHz (Stereo L/R,Ch.1-4, Pan: panned hard left or right)
Main Mix Section: Tape, Aux, Phones output output level 0 dBu Unbalanced, 1/4" jacks
Max out: +22 dBu Unbalanced, 1/4" Jacks
Main EQ (Option): +/-12dB @ 9 bands (63,125, 250 ,500, 1 k, 2 k, 4 k, 8 k,16 kHz)
Noise (Bus noise) ?-90 dB @ 20 Hz 22 kHz (channel & Main level at 0 dB,other at minimum, DSP mute)
Electric Specification Frequency Response: 20 Hz 20 kHz
Output level: 0 dB
S/N Ratio: > 90 dB
Distortion (at 1 KHz): <0.05%
Power SectionSPK. Out Distortion (at 1 W & 1 kHz): <0.1%
Distortion (at 100 W & 1 kHz): <0.15%
Frequency Response (at 100 W): 20 Hz to 22 kHz, +/-2 dBu
SNR (Line In): ?100 dBu
Power continuous
1KHz, THD 1% " 2 X 350 W @ 4 O or 2 X 180 W @ 8 O Power EIAJ
1KHz, THD 1% 2 X 400 W @ 4 O or 2 X 200 W @ 8 O
Thermal protection: Over-temperature power limiting thermal shutdown
Temperature controlled 12V DC fan output
Short-circuit protection
Overload output protection
Over voltage protection
DC offset shutdown
Static PowerConsumption
No Output power state at 230 V ?32 W
100 VAC 50/60 Hz
Power supply Main voltage 110-120 VAC60 Hz
220 - 240 VAC 50 Hz
100 V: T12 A 250 V
110 120 V: T12 A 250 V
220 240 V: T6.3 A 250 V
Dimensions (WxLxH): 304.5mm x 256mm x 74.5mm
Weight: 4.8 kg
