The TX15 comes equipped with efficient, bi-amped Class D amplification that pumps out a generous 600 Watts of peak power. Built to travel, the road-ready TX15 is both lightweight and portable. 600 Watts peak / 300 Watts continuous power and a Net weight of 14.86 kg / 32.8 lbs. This speaker is ideal for Special events, presentations, and weddings.
Ready for AnythingBuilt to travel, the road-ready TX15 is both lightweight and portable. Trapezoid contouring allows either upright or wedge-monitor operation A pole-mount socket and two comfortable handles are built-in. Create a custom setup using the Link output to chain multiple cabinets together. For the musician, DJ, or live-sound provider craving professional audio reproduction, TX15 delivers impressive, accurate sound night after night.
Features:• 600 Watts peak / 300 Watts continuous power
• Efficient Class-D power amp, bi-amplified
• 15" LF woofer with 2" voice coil
• 1" neodymium HF compression driver with 1" voice coil
• Balanced XLR Line Input and Link Output
• Onboard Contour control
• Precision electronic crossover
• Integrated analog limiter and overload protection circuitry
• Lightweight, portable design
• Integrated 36mm speaker pole socket
• Main or wedge monitor operation
• Net weight: 14.86 kg / 32.8 lbs
• Designed in the USA
Applications• Small/Mid-sized PA systems
• Gymnasiums, fitness centers, and dance studios
• Houses of worship
• Bars, restaurants, clubs
• Mobile DJ systems
• Special events, presentations, and weddings
TECH INFORMATIONSystem Type: 2-way active ported speaker
LF Driver: 15" woofer, 2" voice call
HF Driver: 1" ferrite, 1" voice coil
Amplifier: Class D SMPS, 600 watts peak
Horn Coverage: 90H x 45V
Frequency Response (-3dB): 65 Hz - 20 kHz
Crossover Frequency: 2.2 kHz
Max SPL: 119 dB at 1m
Connector: XLR/TRS combo line input & XLR Link output
External Controls: Volume control / Contour / Power ON with green LED / Clip Limiter with red LED
Electronic Protection: Thermal / Overload / Analog Limiter / Compressor
Power Supply: 110V-240V 50/60Hz
Enclosure Construction: Injection-molded polypropylene enclosure, multi-angle for main or monitor applications, metal grille, rubber feet, 2 handles (both sides)
Mounting: 36mm standard pole mount
Dimensions (HxWxD): 650 x 360 x 401 mm
Net Weight: 39.9 lbs / 18.1 kg
