VELOCITY FEATURES:• "PowerTouch" , Touch sensitive interactive jog wheels (Patent pending)
• Digital Scratching 2.0 (Accurate Scratching)
• 2 Scratching modes: Digital Scratch mode, Beat Juggle mode
• 9 On-board FX: Scratch, Filter, Echo, Trans, Skid, Phase, Flanger, Pan, Bop
• Effect layering
• Digital B.P.M. counter: keeps digital FX in sync with music
• 6 Preset Parameters settings for each FX
• Tempo Lock (Master Tempo)
• Lock out mode (Security feature)
• Parameter Ratio adjustment knob
• Parameter Time adjustment knob
• Pitch Bend: 4%, 8%, or 16%
• "Hyper" Pitch (up to 100%)
• 3 Flash Start Sampler Buttons per side (7 second sample per button with or without a CD in drive)
• Flash Cue
• Front Load Dual CD Player
• Anti-shock memory
• Instant start
• Seamless loop
• Fader Q Start
• Reverse play
OTHER FEATURES:• Volume control between music and sampler
• Mixer between music and sampler, can adjust pitches separately
• FX MIX on the fly
• Auto cue function (-48dB)
• 3 sampler (cues) can be memorized
• Selectable elapsed, remain and total remain time display
• Single/continuous play
• Flip Flop (Relay playback between two decks)
SPECIFICATIONS:• Dimensions (WxHxD): MAIN UNIT: 19" x 3.5" x 10" / 482 x 88.8x 251mm (2 rack spaces) • CONTROL UNIT: 19" x 7" x 2" / 482 x 177 x 52mm (4 rack spaces)
• Weight (total): 16 lbs./7.2 kgs.
• Power: AC 115/60Hz or 60Hz/230V switchable
• Power Consumption: 35W
• Frequency Response:20-20KHz +/-1dB
• T.H.D.: 0.03%
• S/N ratio -85 dB
• Over Sampling Rate:8 times
• D/A Conversion:1 bit
• Sampling Rate:44.1k
• Anti-Shock Memory: 10 sec. per side
DX5R FEATURES:• 4 channels with rotary knobs and individual LED indicators
• 8 lines, 2 phono, 2 mics
• Balanced outputs
• Large Master Volume rotary knob
• 4-band rotary EQ: Bass, Mid Low, Mid High, Treble
• Feather Fader crossfader
• Fader-Q-Start with On/Off
• Subwoofer output control
• Gain level knobs for each channel
• "L" shaped case design
• 120V/60Hz or 220V/50Hz Switchable
• Dimensions (LxWxH): 19"x 7" x 4.5" / 482.6 x 177.8 x 114.3mm
• Weight: 7 lbs. / 2.5kg.
