The Antari Z-1020 is a totally new flat horizontal unit that is designed for specialized applications. As unusual as it looks on the outside, the Z-1020 has something all-new inside too - its 1000-watt heater features cutting-edge "mirror pipe technology". This design allows the Z-1020 to be positioned different ways: on the ground to spurt fog upward, mounted sideways on walls, or carried upright like a regular fog machine.
With this versatility, the Z-1020 can produce a variety of unique effects -- from shooting volcanos upward, to creating well-blended atmospheric fog from the wall-mount position. The versatile Z-1020 is great for shows, productions, theme parks, haunted houses, weirdly configured venues, and special applications that cant use a traditional fog machine.
The Z-1020 also includes an electronic low fluid detector with Thermal Cut-Off (TCO) which automatically cuts off the pump power and stops pumping when running-out of fluid. Plus built-in DMX-512 protocol allows users complete control.
Z-1020• Power: AC100V/AC120V/AC230V/AC240V, 50Hz-60Hz
• Heater: 1,000W
• Output: 10,000 cu.ft/min
• First Heat-Up Time: 10 min.
• Tank Capacity: 2.4 Liters
• Fluid Consumption Rate: 13 min/Liter (100% Output)
• Remote Included: Z-10 (Fogging Switch: ON/OFF)
• Optional Remote: Z-40 (Timer Remote); Z-50 (Wireless Remote)
• Optional Accessories: FZ-1020 (Flight Case) holds 2 units in 1 flight case
• Weight: 9.8 Kg
• Dimensions (mm): L370 x W295 x H135
• Liquid Used: Antari FLJ Liquid (Light Red Liquid) recommended
Z-10 Remote• Cable Length: 25 ft.
• Connector: 1/4 Stereo
• Function: Fogging Switch (ON/OFF)
• Compatible with: Z-800II, Z-1000II, Z-1020
