Ultra low-noise ULN design, highest possible headroom, ultra-transparent audio. Effective, extremely musical 3-band EQ plus switchable low-cut filter on all mono channels
• 4 new state-of-the-art, studio-grade IMP "Invisible" Mic Preamps with:
- 130 dB dynamic range for 24-bit, 192 kHz sampling rate inputs.
- Ultra-wide 60 dB gain range
- Lowest possible distortion 0.0007% (20 Hz - 20 kHz)
• 8 balanced high-headroom line inputs with +4/-10 level selection on stereo channels.
• State-of-the-art 4580 operational amplifiers provide lowest noise and distortion-better than 4560 op amps
• 2 aux sends per channel: 1 pre fader for monitoring applications, 1 post fader for external FX devices
• Peak LEDs and mute/alt 3-4 function on all channels.
• 2 subgroups with separate outputs for added routing flexibility.
• 2 multi-functional stereo aux returns with flexible routing.
• Balanced main mix outputs with gold-plated XLR connectors plus separate control room, headphones and stereo tape outputs.
• Control room/phones outputs with multi-input source matrix .
• Tape inputs assignable to main mix or control room/phones outputs.
• Switchable +48 V phantom power for condenser microphones.
• Long-wearing 60 mm logarithmic-taper ALPS faders and sealed rotary controls.
• Internal switch-mode power supply for maximum flexibility (100 - 240 V), noise-free audio, superior transient response plus lowest possible power consumption for energy saving.
• Extremely rugged steel construction ensures long life even under the most demanding conditions.
• Rack mount brackets included.
• Manufactured under ISO9000 certified management system.
|Product Condition||New - On Clearance|
