You get all the important elements right here in a 19" form-factor... Ultra low-noise ULN design, highest possible headroom, ultra-transparent audio. Effective, extremely musical 3-band EQ with semi-parametric mid band plus switchable low-cut filter on all mono channels.
FEATURES:• 4 new state-of-the-art, studio-grade IMP "Invisible" Mic Preamps with:
- 130 dB dynamic range for 24-bit, 192 kHz sampling rate inputs
- Ultra-wide 60 dB gain range
- Lowest possible distortion 0.0007% (20 Hz - 20 kHz)
• Integrated 24-bit digital stereo FX processor with 99 great-sounding VIRTUALIZER presets including reverb, delay, chorus, compressor, tube distortion, vinylizer and more plus 1 kHz test tone generator
• Inserts on each mono channel for flexible connection of outboard equipment
• 12 balanced high-headroom line inputs with +4/-10 level selection on stereo channels
• State-of-the-art 4580 operational amplifiers provide lowest noise and distortion better than 4560 op amps
• 2 aux sends per channel: 1 pre/post fader switchable for monitoring/FX applications, 1 post fader (for internal FX or as external send)
• Peak LEDs, mute, main mix and subgroup routing switches, solo and PFL functions on all channels
• 2 subgroups with separate outputs for added routing flexibility
• 2 multi-functional stereo aux returns with flexible routing
• Main mix outputs with jack and gold-plated XLR connectors, separate control room, headphones and stereo tape outputs
• Control room/phones outputs with multi-input source matrix
• Tape inputs assignable to main mix or control room/phones outputs
• Switchable +48 V phantom power for condenser microphones
• Long-wearing 60 mm logarithmic-taper ALPS faders and sealed rotary controls
• Internal switch-mode power supply for maximum flexibility (100 - 240 V), noise-free audio, superior transient response plus lowest possible power consumption for energy saving
• Extremely rugged steel construction ensures long life even under the most demanding conditions
• Rack mount brackets included
• Manufactured under ISO9000 certified management system
