It features 4/5/9 or 10 DMX channel modes, which means it works great with any type of controller, including popular 4-channel controllers. You'll have full control of all that RokBox' 5 has to offer such as RGBAW color mixing, 31 built-in programs, ultra smooth flicker-free 32-bit dimming (5 user-selectable dimming curves), and even easy HSV color mixing ability in 4-channel mode.
The super-easy to use built-in 4-button LED control panel also allows total control over the fixture including master/slave settings, sound active mode, built-in programs, auto mode, custom RGBAW color mixing, and user adjustable fade/strobe effects for a totally rocking light show!
It also comes equipped with industry standard powerCON compatible power input/output connections & 3-pin DMX connections which are all strategically placed on the back of the unit in a way that allows you to use the RokBox' 5 RGBAW in ANY position, including flat on the floor. This makes the RokBox' 5 RGBAW a perfect solution for any of your uplighting and/or truss warming needs!
• RGBWA color mixing via 18x 15W Red/Green/Blue/Amber/White 5-in-1 LEDs
• 5 user-selectable 32-bit dimming curves
• Variable electronic dimming & strobe
• Built-in color & chase macros via DMX
• Built-in automated programs via master/slave
• Built-in sound active programs
• RGBAW color mixing ability in standalone mode
• Rugged and well-built (It hits the gym regularly)
• Super-quiet variable-speed internal fan cooling
• Dual mounting brackets for positioning flexibility
• Flicker-free constant-current 400hz LED driver
• 3-pin male input and 3-pin female output
• PowerCon' compatible AC power In/Out connectors
• Operating Voltage: 90-230VAC, 50-60 Hertz
• Fuse: 3A 250V
• Power Consumption: 154W
• LED: 18x 15W 5-in-1 LEDs 100,000 hours.
• Beam Angle: 25 degree optics standard, 26 degree beam, 30 degree field
• Max. Operating Temp.: 104 degrees F (40 degrees C) ambient
• Protocol: USITT DMX-512
• DMX Channels: 4/5/9/10
• Input: 3-pin XLR Male
• Output: 3-pin XLR Female
• HSV (4-Ch), RGBAW (5-Ch), Extended (9-Ch), and Extended plus 32-bit Dimming (10-Ch) DMX Profiles
• Operating Modes: Standalone, Master/Slave, Sound Active, Color Preset
Weight & Dimensions
• Length: 9.22 inches (234 mm)
• Width: 6.5 inches (165 mm)
• Height: 8.98 inches (228 mm)
• Weight: 7.28 lbs (3.3 kg)
• 2-year limited warranty, does not cover malfunction caused by damage to LED's.
