4Bar Flex T USB Features• Upgraded version of the popular 4BAR Tri USB increases FLEXibility
• Mounts to most tripods or speaker stands, without the need for additional clamps, using the pass-through hole
• D-Fi' USB compatibility for wireless master/slave or DMX control
• Create the ultimate light show by mounting up to 4 additional fixtures to the top of the 4BAR Flex
• Provide electricity to the additional lights by using the built-in Edison plugs
• Maximize setup possibilities and configurations with 2 included L-brackets
• Easily set up and tear down in minutes with the included carrying bag
• Multiple control options include standalone, DMX mode, wireless footswitch or the IRC-6
• Safely mounts to truss using built-in bolts
• Create large, coordinated light shows with other 4BAR fixtures in master/slave mode
4Bar Flex T USB Specs• DMX Channels: 3 or 15
• DMX Connectors: 3-pin XLR
• Light Source: 28 LEDs (tri-color RGB) 3 W, (800 mA), 50,000 hours life expectancy
• Strobe Rate: 0 to 22 Hz
• Beam Angle: 18 (per pod)Field Angle: 31 (per pod)
• Illuminance: 2330 lux @ 2 m (per pod)
• Power Linking:
- 8 units @ 120 V
- 16 units @ 230 V
• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current:
- 64 W, 1 A @ 120 V, 60 Hz
- 63 W, 0.5 A @ 230 V, 50 Hz
• Weight:
- 11.6 lb (5.3 kg)
- (Controller): 0.8 lb (1.8 kg)
Size:
- 47.4 x 5.5 x 14.75 in (1205 x 140 x 374.8 mm)
- (Controller): 12.4 x 5.2 x 1.5 in (315 x 131.5 x 37.5 mm)
• Approvals: CE
4Bar Flex T USB Features• Upgraded version of the popular 4BAR Tri USB increases FLEXibility
• Mounts to most tripods or speaker stands, without the need for additional clamps, using the pass-through hole
• D-Fi' USB compatibility for wireless master/slave or DMX control
• Create the ultimate light show by mounting up to 4 additional fixtures to the top of the 4BAR Flex
• Provide electricity to the additional lights by using the built-in Edison plugs
• Maximize setup possibilities and configurations with 2 included L-brackets
• Easily set up and tear down in minutes with the included carrying bag
• Multiple control options include standalone, DMX mode, wireless footswitch or the IRC-6
• Safely mounts to truss using built-in bolts
• Create large, coordinated light shows with other 4BAR fixtures in master/slave mode
4Bar Flex T USB Specs• DMX Channels: 3 or 15
• DMX Connectors: 3-pin XLR
• Light Source: 28 LEDs (tri-color RGB) 3 W, (800 mA), 50,000 hours life expectancy
• Strobe Rate: 0 to 22 Hz
• Beam Angle: 18 (per pod)Field Angle: 31 (per pod)
• Illuminance: 2330 lux @ 2 m (per pod)
• Power Linking:
- 8 units @ 120 V
- 16 units @ 230 V
• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current:
- 64 W, 1 A @ 120 V, 60 Hz
- 63 W, 0.5 A @ 230 V, 50 Hz
• Weight:
- 11.6 lb (5.3 kg)
- (Controller): 0.8 lb (1.8 kg)
Size:
- 47.4 x 5.5 x 14.75 in (1205 x 140 x 374.8 mm)
- (Controller): 12.4 x 5.2 x 1.5 in (315 x 131.5 x 37.5 mm)
• Approvals: CE
• Optional Controllers: IRC 6, D-Fi USB
