COLORdash' Quad wash light offers 3, 4, 10 or 12-channel operating modes and rich, saturated colors induced by RGB color mixing from 36 high powered LEDs. Use the automated programs via master/slave or DMX.
This stackable wash is also custom programmable with recall and custom programs that can be transferred between fixtures. The 25 x 6 lens produces a wide linear beam for bright, seamless wall washes. The double bracket can be used as a floor stand or to hang the fixture.
FEATURES: • 3, 4, 10 or 12 channel DMX 512 wash light (with ID addressing)
• Operating modes
3 channel: RGB
4 channel: RGB, Dimmer
10 channel: RGB, ID, Dimmer, Macro, Strobe, Automatic, • Custom, Module Select
12 channel: RGB control of each block
• RGB color mixing with or without DMX controller
• Built-in automated programs via master/slave or DMX
• Program and recall custom programs via master/slave or DMX
• High Power, 1W (350mA) LEDs
• Adjustable fan speed
• Additional (IEC) power output: max 10 units @ 120V. (see manual for details)
• Includes 6.6ft. (2m) power extension cable
• LCD display with password protection
• Transfer custom programs between fixtures
• Double-bracket yoke doubles as floor stand
• 3 pin or 5 pin DMX operation
• Multiple mounting options (linear or array) with included brackets
OPTIONS • COLORado' Controller (COLOR-CON)
• Optical systems 15(CL20X15), 30 (CLENS3009), 25x6(installed)
VIDEO
SPECIFICATIONS: • Beam Angle: 25 x 10
• Field Angle: 46 x 21
• Lux: 4,800 @ 1 m 1,227 @ 2 m
• Light source: 36 (12 x 350 mA red, 12 x 350 mA green, 12 x 350 mA blue) LEDs, 50,000 hrs
• Power and Current: 120 V, 60 Hz; 59 W, 0.870 A (operating), 0.3 A (inrush)
• Power and Current: 230 V, 50 Hz; 57 W, 0.462 A (operating), 0.4 A (inrush)
• AC power: Auto-ranging 100 V 240 V 50/60 Hz
• Weight: 9.9 lbs / 4.9 kg
• Size: 21 x 5 x 7.5 in / 533 x 127 x 190 mm
