FeaturesCONTROL FEATURES • 7-channel DMX-512 moving yoke
• Pan: 510 / tilt: 260
• Pan/tilt speed & reset control channel
• Mechanical dimmer/shutter/strobe
• Blackout, reset, sound activation and built-in automatic programs via DMX
• Color wheel:
- 8 colors + white
- Rainbow color spin in both directions, at variable speeds
• Gobo wheel:
- 7 gobos + open
- Gobo wheel spin in both directions, at variable speeds
ADDITIONAL FEATURES• Dual hanging brackets with -turn fasteners
• Built-in automated programs via master/slave or DMX
• Built-in sound activated programs via master/slave or DMX
• Compact and lightweight
• LED display menu with invert
• Pan/tilt invert option
• Micro-stepping motors
• Thermal switch & fan cooled
SPECIFICATIONSBeam angle: 11
Footcandles: 2330 @ 1 meter
Lux: 25,070 @ 1 meter
Bulb: ELC3 24V 250W
Current draw: (peak 312W @ 120V)
Power: 110V or 230V
Weight: 12.76lbs (5.79kgs)
Master packed: 2pcs / 26lbs (11.79kgs)
Size: 16in x 10in x 9in
406.4mm x 254mm x 228.6mm
2-year limited warranty
