Gobo Zoom USB is a super compact gobo projector with a manual zoom, and wireless connectivity in master/slave and DMX mode, thanks to its embedded D-Fi USB compatibility. Gobo Zoom USB includes 10 wedding-ready gobos. Gobo Zoom USB can be controlled without DMX using the optional IRC-6 remote (sold separately). Gobo Zoom USB accepts custom gobos, including patterns and messages easily printed on transparency film. Fits best in the CHS-40 VIP Gear Bag.
VIDEO
VIDEO
Features • Super-compact custom gobo projector, with built-in D-Fi USB compatibility that allows for instant wireless connectivity
• D-Fi USB compatibility for wireless Master/Slave or DMX control
• Control dimmer, gobo rotation and direction with the built-in display or optional IRC remote
• Manual zoom for short-throw or long-throw applications
• Includes 10 wedding ready gobos
• Access all functions via the optional IRC-6 remote
• User-configurable standalone operation provides excellent control without DMX
• Print your own custom gobos on transparency film
• Fits best in the CHS-40 VIP Gear Bag
Specifications • DMX Channels: 2
• DMX Connectors: 3- pin XLR
• Light Source: 1 LED (cool white) 25 W (6 A), 50,000 hours life expectancy
• Illuminance: (17) 3,075 lux @ 2 m; (28) 1,121 lux @ 2 m
• Power Linking: 13 units @ 120 V; 24 units @ 230 V
• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current: 41 W, 0.7 A @ 120 V, 60 Hz; 39 W, 0.3 A @ 230 V, 50 Hz
• Gobo Size: 25.74 mm outside, 19.38 mm max image, 1 mm max thickness
• Zoom Angle: (manual): 17 to 28
• Weight: 4.4 lb (2.1 kg)
• Size: 9.4 x 4.9 x 9.6 in (238 x 124 x 244 mm)
• Approvals: CE
• Optional Controllers: IRC-6
