The LEDrain' 56 is a 7-channel DMX LED narrow beam fixture that features blackout, static, dimmer, and strobe functions. The unit can switch between sound-active and automatic modes, with static colors and RGB color mixing available via dip switches or through DMX control. Power is daisy-chainable to 50 units, allowing for shorter cable runs.
FEATURES:• 7-channel DMX-512 LED narrow beam
• Blackout/static/dimmer/strobe
• Selector switch for sound active or automatic mode
• Static colors and RGB color mixing with or without DMX controller
• Additional power output: max 50 units @ 120V (see manual for details, 115V models only)
• Linkable power with other LEDrain' and LEDsplash' units (115V models only)
• Built-in automated programs via master/slave
• Built-in sound activated programs via master/slave
• Double-bracket yoke doubles as floor stand
SPECIFICATIONS:• Beam angle: 16
• Field angle: 25
• Lux: 1,743 @ 1m
• Light Source: 108 (36 red, 36 green, 36 blue) 10mm LEDs 100,000hrs
• Power and current: 120V, 60Hz: 12W 0.1A operating, 0.2A inrush
• AC power: Autoswitching 100V - 240V 50/60Hz
• Weight: 3.3lbs (1.5kg)
• Size: 10.3in x 9.3in x 7.5in (260mm x 234mm x 191mm)
