• Full Color LED (RGBAL), convection cooled houselight
• Interchangeable lens plates to adapt to different mounting heights
• 5-pin XLR and terminal blocks for DMX connections
• Use included yoke for pipe mounting, or suspend from integrated loop-eye
• Virtual Color wheel with color matched to popular gel colors
• Color Temperature Presets from 2800 K to 6500 K with high CRI and CQS
• 16-bit dimming for ultra-smooth fades
• DMX, WDMX and RDM (Remote Device Management) for added programming flexibility
• Adjustable PWM (Pulse Width Modulation) to avoid flickering on camera
Optical• Light Source: 60 LEDs (12 red, 12 green, 12 blue, 12 amber, 12 lime) 2 to 3 W, (800 mA), 4766 K, 50,000 hours life expectancy
• Color Temperature (at full): 4766 K
• CRI (5000 K): 90
• Beam Angle (no lens): 28
• Beam Angle (w/80 filter): 40
• Beam Angle (w/65 lens): 51
• Beam Angle (w/45 lens): 39
• Beam Angle (w/25 lens): 37
• Field Angle (no lens): 60
• Field Angle (w/80 filter): 80
• Field Angle (w/65 lens): 79
• Field Angle (w/45 lens): 66
• Field Angle (w/25 lens): 37
• Dimming Modes: 4
• Illuminance (no lens): 545 lux @ 5 m
• Illuminance (w/80 filter): 163 lux @ 5 m
• Illuminance (w/65 lens): 171 lux @ 5 m
• Illuminance (w/45 lens): 349 lux @ 5 m
• Illuminance (w/25 lens): 1,047 lux @ 5 m
• Lumens (w/no lens): 4,410
• Lumens (w/80 filter): 2,694
• Lumens (w/65 lens): 3,769
• Lumens (w/45 lens): 3,769
• Lumens (w/25 lens): 3,938
• Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6000 Hz, 25,000 Hz
Dynamic Effects• Dimmer: Electronic
• Shutter/Strobe: Electronic
• Strobe Rate: 0 to 27 Hz
• Standalone Color Mixing: Yes
• Color Temperature Presets: Yes
• Dim Modes: 4
• Built-in Automated Programs: Yes
Construction / Physical• Dimensions: 13.11 x 9.44 x 13.34 in (333 x 240 x 339 mm)
• Weight: 19.6 lb (8.9 kg)
• Exterior Color: Black or White
Connections• Power Connection: Bare-wired
• Power Input: Hard-wired
• Data Connectors: 5-pin XLR, Phoenix connector
• Cable Length (power): 15 ft (4.5 m)
Control• Control Protocol:, DMX, RDM, W-DMX'
• DMX Channels: 2, 4, 5, 8, 11, 13, 14, 16 or HSV
• Modes/Personalities: 9 personalities (2, 4, 5, 8, 11, 13, 14, 16, HSV)
Electrical• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current: 142 W, 1.19 A @ 120 V, 60 Hz
• Power and Current: 146 W, 0.704 A @ 208 V, 60 Hz
• Power and Current: 145 W, 0.627 A @ 230 V, 50 Hz
Certifications / Qualifications• CE, MET, FCC
• IP Rating: IP20, dry location
What's Included• Ovation H-605FC
• 65, 45 and 25 lenses
• 80 filter
Optional Accessories• W-DMX' Transmitter
• Professional Clamps: CTC-50HC, CTC-50HCN
• 5-pin DMX Cables
• RDM2go
