The RDM2go is a multi-functional tool for working with fixtures over a DMX/RDM data line. The palm-sized controller performs a multitude of tasks including RDM functionality, DMX snapshot and test-scene record and playback, Ilumicode addressing for Iluminarc fixtures and DMX input and output monitoring. The RDM2go also features a built in DMX cable integrity checker, and an easy to ready OLED display. The unit easily recharges via a standard micro USB jack and comes with a convenient carry pouch and connector convertors.
Chauvet Professional RDM2go Features• Handheld tool for managing fixtures and systems with DMX, RDM, and Ilumicode based control
• Easily address, locate and monitor RDM capable fixtures
• Check DMX addressing, cabling, and store/playback basic snapshots
• Address and set personalities of Ilumicode based architectural fixtures
• Address and set personalities of Ilumicode based architectural fixtures
• Comes with connector adaptors, USB charging cord and belt clip pouch
Chavuet Professional RDM2go SpecsDYNAMIC EFFECTS
• Standalone Color Mixing: Yes
• Color Temperature Presets (Ilumicode): Yes
• Dim Modes (Ilumicode): 5
• Customizable Programs: Yes
• Recall Custom Programs: Yes
CONSTRUCTION / PHYSICAL
• Dimensions: 2.76 x 1.52 x 3.92 in (70 x 39 x 100 mm)
• Weight: 0.77 lb (0.35 kg)
• Exterior Color: Black
• Exterior Color: Black
CONNECTIONS
• Power Input: Micro USB-B Male
• Data Connectors: 5-pin XLR
• Cable Length (power): 3 ft (0.91 m)
CONTROL
• Protocol(s): DMX, RDM, Ilumicode
• DMX Channels: 1, 2, 3, 4, 5, 6 or 7
• Modes/Personalities (Ilumicode): 13 personalities (ARC 1, ARC 1+D, ARC2, ARC2+D, ARC3, ARC3+D, ARC FULL, REMOTE, SOLID, SPECIAL1, SPECIAL2, VW, VW+D)
ELECTRICAL
• Power and Current: 18 W, 0.15 A @ 120 V, 60 Hz
• Power and Current: 18 W, 0.09 A @ 208 V, 60 Hz
• Power and Current: 18 W, 0.08 A @ 230 V, 50 Hz
BATTERY
• Battery type: Lithium IonRechargeable: YesBattery Life: 8 hoursBattery Power: 3.7 V, 1,200 mAh
CERTIFICATIONS / QUALIFICATIONS
• CEIP Rating: IP20, dry location
WHAT'S INCLUDED
• RDM2go
• Carry Pouch
• 2 pc, 3- to 5-pin converters
• 5-pin male to bare wire adaptor
• USB-A Male to Micro USB-B Male (3 ft)
