Features• Fully featured IP65 rated RGBW LED yoke wash fixture
• Durable and lightweight aluminum/magnesium alloy body
• Smooth fades with 16-bit individual color and master dimming
• 8 to 66 zoom
• 19 RGBW LEDs, 25W each
• 5-pin DMX input/output connections
• 5 zones of LED control for pixel mapping control
• Fast, smooth pan and tilt movement
• RDM enabled for remote addressing and trouble shooting
• Selectable PWM options for camera operation
• User selectable calibrated white, 7500K default calibration
• 6 distinct dimming modes for advanced control
• Easy to read OLED display with simple, effective menu options
• Simple and complex DMX channel profiles for programming versatility
• USB-C port for uploading software
Optical• Light Source: 19 LEDs (quad-color RGBW) 25 W, (1.5 A), 50,000 hours life expectancy
• Color Temperature (range): 2800 to 10000 K
• Beam Angle: 8 to 36.1
• Field Angle: 11.8 to 53
• Cutoff Range: 17.5 to 66.1
• Zoom Range: 8 to 66.1
• Lumens Source: n/a
• Lumens Output: 6,258
• Illuminance (11.8): 8,713 lux @ 5 m
• Illuminance (53): 694 lux @ 5 m
• Selectable PWM: 600Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 15,000 Hz
Dynamic Effects• Pan and Tilt: 540/270
• Pan and Tilt Ranges: 180, 360, 540 pan/90, 180, 270 tilt
• Dimmer: Electronic
• Shutter/Strobe: Electronic
• Zoom: Motorized
• Strobe Rate: 0 to 20 Hz
• Standalone Color Mixing: Yes
• Color Temperature Presets: Yes
• Dim Curves: 6
• Built-in Automated Programs: Yes
• Customizable Programs: No
• Recall Custom Programs: No
Construction / Physical• Dimensions: 11.92x8.58x14.1" (303x218x361mm)
• Weight: 23.4 lb (10.6 kg)
• Exterior Color: Black
• Housing Material: Aluminum/magnesium alloy, High-impact flame-retardant polymer
Connections• Power Connection: Bare ended to Seetronic IP65 PowerKon
• Power Input: Seetronic IP65 PowerKon
• Power Output: Seetronic IP65 PowerKon
• Data Connectors: 5-pin XLR
• Cable Length (power): 5 ft (1.5 m)
Control• Control Protocol: DMX, RDM
• DMX Channels: 15, 17, 22, 33, 54, or 56
• Modes/Personalities: 8 personalities (15CH, 17CH, 22CH, 33CH, 33CH MS, 54CH, 54CH MS or 56CH)
Electrical• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power Linking: 5 units @ 120 V; 9 units @ 208 V; 10 units @ 230 V
• Power and Current: 291 W, 2.47 A @ 120 V, 60 Hz
• Power and Current: 284 W, 1.41 A @ 208 V, 60 Hz
• Power and Current: 282 W, 1.28 A @ 230 V, 50 Hz
Certifications / Qualifications• CE, MET, FCC, UKCA
• IP Rating: IP65 (temporary wet location)
What's Included• Rogue Outcast R2X Wash IP
• Seetronic powerCON power cord
Optional Accessories• Professional Clamps: CTC-50HC, CTC-50HCN
• Safety Cable: SC-07
• Seetronic IP65 PowerKon cables
• DMX Cables
• Flight Case:CP6CASER2W
