A color wheel equipped with 14 colors complimented by a gobo wheel with 17 gobos give you a wealth of dynamic effects, and both wheels are fully scrollable at variable speeds. Additionally, the unit features individually overlapping 8 and 24-facet prisms for an endless supply of creative beam looks. The unit is equipped with RDM and DMX protocols and features multiple control personalities.
Optical• Fully featured RGBW LED yoke wash fixture with LED zone control and zoom
• 16-bit Dimming of master dimmer as well as individual colors for smooth control of fades
• 37 RGBW LEDs, 15 W each
• 9 zones of LED control for pixel mapping effects
• Unique lens design offers excellent color mixing
• 6 distinct dimming modes for different dimming needs
• Easy to read OLED display with simple, effective menu options
• Simple and complex DMX channel profiles for programming versatility
• RDM (Remote Device Management) for added programming flexibility
Dynamic Effects• Pan and Tilt: 540/270
• Pan and Tilt Ranges: 180, 360, 540 pan/90, 180, 270 tilt
• Colors: 14 + white, split colors, continuous scroll at variable speeds
• Gobos : 17 + open (17 metal), continuous scroll at variable speeds
• Dimmer: Motorized
• Shutter/Strobe: Motorized
• Focus: Motorized
• Frost: Motorized
• Prism: 8 facets, motorized, rotating
• Prism: 24 facets, motorized, rotating
• Strobe Rate: 0 to 15 Hz
• Move in Black: Yes
Construction / Physical• Dimensions: 12.79 x 8.66 x 21.65 in (325 x 220 x 550 mm)
• Weight: 34.4 lb (15.6kg)
• Exterior Color: Black
• Housing Material: High-impact flame-retardant polymer
Connections• Power Connection: Edison (Local) plug to Neutrik
• Power Input: Neutrik powerCON
• Power Output: Neutrik powerCON
• Data Connectors: 3- and 5-pin XLR
• Cable Length (power): 5 ft (1.5 m)
Control• Control Protocol: DMX, RDM
• DMX Channels: 16 or 19
• Modes/Personalities: 2 personalities (16, 19)
Electrical• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current: 422 W, 4.20 A @ 100 V, 60 Hz
• Power and Current: 418 W, 3.55 A @ 120 V, 60 Hz
• Power and Current: 411 W, 1.98 A @ 208 V, 60 Hz
• Power and Current: 411 W, 1.78 A @ 230 V, 50 Hz
• Power and Current: 406 W, 1.68 A @ 240 V, 50 Hz
Certifications / Qualifications• CE, MET
• IP Rating: IP20, dry location
• Temperature (Ambient): -4 F to 113 F (-20 C to 45 C)
What's Included• Rogue R3 Beam
• Neutrik powerCON power cord
• 2 Omega brackets with mounting hardware
Optional Accessories• Professional Clamps: CTC-50HC, CTC-50HCN
• Safety Cable: SC-07
• DMX cables
• Flight Case: #CP2CASER2XR3SPOT
• UPLOAD 08 software uploader
