CONTROL FEATURES• 6-7 channel DMX-512 scanner
• Pan: 180
• Tilt: 70(Q-Scan'250)
• Barrel rotation: 360(Q-Roll'250)
• Mechanical dimmer/shutter/strobe
• Rotating gobos
- 8 interchangeable rotating gobos + open
- 6 metal, 2 glass installed
- Additional free gobos: 2 metal
- Gobo Bounce'
- Gobo wheel spin in both directions, at variable speeds
• Color wheel
- 11 colors + white
- includes 1 quad and 1 tri-color split
- Rainbow color spin in both directions at variable speeds
• Gobo rotation control channel
• Pan speed & reset control channel
ADDITIONAL FEATURES• Built in beat-activated and automated programs (stand-alone)
• Master/Slave, sound & auto, ILS' compatible mode
• LED display menu with invert
• Pan/Tilt invert option
• Display auto On/Off
• Removable foot stands
• Micro-stepping motors
• Thermal switch
• Fan cooled
OPTIONAL CONTROLLERSAny universal DMX-512 controller
SPECIFICATIONS• Gobo size: 27.8mm outside, 21.5mm image,
1mm max. thickness
• Beam angle: 16 (Q-Roll'250); 15 (Q-Scan'250)
• Bulb: HSD250/80 250W 8000K 3,000hrs
• Current draw:
(peak 240W @ 120V)
(inrush 610W @ 120V)
(peak 264W @ 230V)
(inrush 670W @ 230V
• Power: Switchable 110V/230V
• Weight: 32lbs (14.52kgs)
• Size: 11.5in x 12in x 29in
292.1mm x 304.8mm x 736.6mm
• 2-year limited warranty
