CONTROL FEATURES• 6-9 channel DMX-512 moving yoke
• Pan: 540 / Tilt: 270
• Pan/Tilt speed & reset control channel
• Mechanical dimmer/shutter/strobe
• Rotating gobos
- 7 interchangeable rotating gobos + open
- 5 metal, 2 glass installed
- Additional free gobos: 2 metal
- Gobo Bounce'
- Gobo wheel spin in both directions at variable speeds
• Color wheel
- 9 colors + white
- Rainbow color spin in both directions, at variable speeds
• Gobo rotation control channel
ADDITIONAL FEATURES• Automatic pan & tilt correction
• Built in beat activated and automatic programs (stand-alone)
• Master/slave, sound & auto, ILS' compatible mode
• User selectable 8 or 16 bit movement resolution
• LED display menu with invert
• Pan/Tilt invert option
• Display auto On/Off
• Micro-stepping motors
• Thermal switch & fan cooled
OPTIONAL CONTROLLERS:Any universal DMX-512 controller
SPECIFICATIONS• Gobo size: 27.8mm outside, 21.5mm image, 1mm max. thickness
• Beam angle: 16
• Bulb (Q-Spot'): EHJHLXX 250W 24V specially designed for CHAUVET' 700hrs
• Bulb (Q-Spot'150): HTI150 150W 6500K 750hrs
• Current draw (Q-Spot'):
(peak 324W @ 120V), (inrush 720W @ 120V)
(peak 359W @ 230V), (inrush 741W @ 230V)
• Current draw (Q-Spot'150):
(peak 251W @ 120V), (inrush 466W @ 120V)
(peak 289W @ 230V), (inrush 433W @ 230V)
• Power: Switchable 110V/230V
• Weight (Q-Spot'): 31.4lbs (14kgs)
• Weight (Q-Spot'150): 33.6lbs (15kgs)
• Size: 12in x 12.5in x 18.5in 304.8mm x 317.5mm x 469.9mm
• 2-year limited warranty
