CONTROL FEATURES• 13-channel DMX-512 moving yoke
• Pan: 530/ Tilt: 280
• Pan/Tilt speed & reset control channel
• Lamp On/Off, reset channel
• Color wheel
- 7 colors + white
- Rainbow color spin at variable speeds
• 3-facet high speed rotating prism
• Indexed rotating gobo wheel
- 5 interchangeable rotating gobos + open
- 3 metal, 2 glass installed
- Additional free gobos: 4 metal, 1 glass
- Gobo wheel spin at variable speeds
- Gobo Bounce'
• Gobo index & rotation control channel
• Motorized focus
• Mechanical shutter/strobe/dimmer
ADDITIONAL FEATURES• Automatic pan & tilt correction
• Built in automated programs (with master/slave)
• Built in sound-active programs (with master/slave)
• Display auto On/Off
• 16-bit pan & tilt resolution
• Micro-stepping motors
• Thermal switch & fan cooled
OPTIONAL CONTROLLERSAny universal DMX-512 controller
SPECIFICATIONS• Gobo size: 37.2mm outside, 31mm image,
1mm max. thickness
• Beam angle: 21
• Bulb: HSD250 250W 8000K 3,000hrs
• Current draw: (peak 252W @ 120V), (inrush 288W @ 120V)o Power: Internal multi-tap transformer 100V, 115V, 200V, 230V / 50Hz or 60Hz
• Weight: 55.12lbs (25kgs)
• Size: 15.75in x 15.75in x 18.74in 400mm x 400mm x 476mm
• 2-year limited warranty
