CONTROL FEATURES:• 13 or 16-channel DMX-512 moving yoke
• Pan: 530 / tilt: 280
• Variable strobe/shutter
• Color wheel
7 colors + white
Rainbow color spin at variable speeds
• Static gobo wheel
4 interchangeable, slot-n-lock gobos + open
2 metal, 2 glass installed
2 CT filters (3200K & 5000K)
Gobo Bounce'
• Indexed rotating gobo wheel
5 interchangeable, indexing rotating + open
2 metal, 3 glass installed
Rotating gobo wheel spin at variable speeds
Gobo Bounce'
• Frost filter for color washing
• 3-facet, high-speed rotating prism in both directions at variable speeds
• Variable motorized focus
• Variable motorized dimmer (0 - 100%)
• Remote fixture reset, lamp on/off & vector speed channel
• Built-in effect macros via DMX (gobo, gobo rotation, color, strobe, prism)
ADDITIONAL FEATURES:• User-selectable pan/tilt ranges
• Automatic pan & tilt correction
• Built-in automated programs via master/slave • Built-in sound-active programs via master/slave
• User-selectable basic or advanced operating modes
• LCD display with lock-out feature
• Micro-stepping motors
• Display auto on/off
• Thermal switch
• Fan cooled
SPECIFICATIONS:• Beam angle: 20
• Footcandles: 4,010
• Lux: 43,148
• Light source: MSD250 250W 8000K 2,000hrs
• Current draw: (peak 370W @ 120V) (inrush 253W @ 120V)
• Power: Switchable (internal) 100V,115V, 200V, 230V - 50 or 60Hz
• Weight: 62lbs (28kgs)
• Size: 15.3in x 17.8in x 20.5in
389mm x 452mm x 521mm
• 2-year limited warranty
