CONTROL FEATURES• 16-channel DMX-512 moving yoke
• Mechanical dimmer (0100%)
• Variable strobe/shutter
• Color wheel
- 10 colors + white
8 solid colors, 1 split color, 1 quad color
- Rainbow color spin in both directions at variable speeds
• Static gobo wheel
- 9 interchangeable gobos + open
- Gobo wheel spin in both directions at variable speeds
- Gobo Bounce'
• Indexed rotating gobo wheel
- 6 interchangeable rotating + open
- 3 metal, 3 dichroic installed
- Additional gobos: 1 dichroic & 4 metal
- Rotating gobo wheel spin in both directions at variable speeds
• 3-facet high speed rotating prism
- Rotating prism in both directions at variable speeds
• Motorized focus
• Pan: 540 / Tilt: 270
• Remote fixture reset channel
• Lamp On/Off
ADDITIONAL FEATURES• Automatic pan & tilt correction
• Micro-stepping motors
• LED display
• Display auto On/Off
• Built in automated programs (with master/slave)
• Built in sound-active programs (with master/slave)
• User selectable 16-bit or 8-bit resolution
• Thermal switch
• Fan cooled
• Removable air filter
OPTIONAL CONTROLLERSAny universal DMX-512 controller
SPECIFICATIONS• Gobo size
• Rotating: 31mm outside, 22.5mm image, 3mm max. thickness
- Static: 31mm outside, 22.5mm image, .2mm max. thickness
• Beam angle: 21
• Bulb: HMI575/GS 575W 6000K 1,000hrs
• Current draw: peak 936W @ 120V
• Power: Switchable (internal) 100V,115V, 200V, 230V - 50/60Hz
• Weight: 74lbs (33.6kgs)
• Size: 15.9in x 13.7in x 254in
404mm x 348mm x 529mm
• 2-year limited warranty
