CONTROL FEATURESL• 16-channel DMX-512 moving yoke color wash
• Pan: 540 / tilt: 270
• Variable strobe/shutter
• CMY color mix system (cyan, magenta, yellow wheels)
• Color wheel
6 colors + white
Red, blue, green, purple, 3200K & 5000K correction filters
Rainbow color spin in both directions at variable speeds
• 31 color macros
• Beam shaper effect
• Frost filter
• Variable motorized zoom (26 - 34)
• Variable motorized dimmer (0 - 100%)
• Remote fixture reset, lamp on/off and vector speed channel
• Vector speed channel for CMY color mix system
ADDITIONAL FEATURES:• Automatic pan & tilt correction
• Micro-stepping motors
• LED display
• 16bit pan/tilt resolution
• Thermal switch
• Fan cooled
SPECIFICATIONS:• Beam angle: 26 & 34
• Footcandles: 5,400
• Lux: 58,104
• Light source: HMI575/GS 575W 6000K 1,000hrs
• Current draw: (peak 720W @ 120V), (inrush 1,224W @ 120V)
• Power: Switchable (internal) 100V, 115V, 200V, 230V - 50 or 60Hz
• Weight: 75.8lbs (34kgs)
• Size: 16in x 16in x 23in
406mm x 406mm x 584mm
• 2-year limited warranty
