FEATURES:• 40 GB internal hard drive (DN-V755 only)
• PCMCIA Flash Card slot (DN-V750 only)
• Up to 8 hours of DVD quality video
• Internally expandable to 137 GB
• Plays 720 x 480 MPEG-2 at 10 Mbps OR BELOW
• Plays I-Pictures (720 x 480)
• Plays Wav or MPEG-1 (layer II) audio at 44.1 kHz or 48 kHz
• Parallel remote control (Switch closure on 15-pin D-sub)
• Serial control (RS-232C on 9-pin D-sub)
• Ethernet control (LAN/RJ-45)
• Realtime clock for scripted/automated playback of A/V files
• FTP Site Command Server for audio, video, picture and scripting/automation uploads
• Simple Windows application for easy set-up and file transfer
• S-Video and Composite (RCA) video outputs
• Unbalanced (RCA) stereo audio outputs
TECHNICAL SPECIFICATIONS:Playable formats• Movie + sound or movie only
• ISO/IEC 13818-1 MPEG2 MP@ML PS (Program Stream) files (movie + sound)
• ES files (movie only) Resolution : 720 480 (NTSC) / 720 576 (PAL)
Still images
ISO/IEC 13818-2 MPEG2 MP@ML ES files
Resolution : 720 480 (NTSC) / 720 576 (PAL) per frame intraframe
Audio format
MPEG1-Audio Layer 2 (ISO/IEC 11172-3)
Sampling frequency : 48 kHz, 44.1 kHz
Max. bit rate
Max.10 Mbps total for video + audio (as per card performance)
Recording medium• Recommended Flash memory card (DN-V750)
• Built-in hard disc drive (DN-V755)
Input/output terminals• Composite output RCA terminal
• Y/C separated signal output S terminal
• Audio output RCA terminal (stereo)
• DC input terminal, serial mode (D-sub female 9 pin) terminal 10(RS-232C)
• Parallel remote (D-sub female 15 pin) terminal
• Ethernet (LAN) (RJ-45) terminal (10 BASE-T/100 BASE-TX, automatic selection)
Video performance• Video outputs Composite:
1.0 Vp-p (negative resistance 75)
• S-Video Y (brightness) signal:
1.0 Vp-p (negative resistance 75)
• C (color) signal: 286 mVp-p (negative resistance 75) (NTSC)
300 mVp-p (negative resistance 75) (PAL)
• Sampling frequency: 13.5 MHz
• S/N ratio: 50 dB or greater
Audio performance• Output level : 2.0 Vrms (negative resistance 10k:
1 kHz 0 dB playback
• Distortion : 0.1% or less (when playing 1 kHz 0 dB sine wave, using LPF)
• S/N ratio : 80 dB or greater (when playing 1 kHz 0dB sine wave, using LPF and A-Filter)
• Channel separation : 70 dB or greater (stereo, when playing 1 kHz 0 dB sine wave, using LPF
A-Filter)
• Frequency response (1 kHz base): Within 0 3 dB at 20 to 20 kHz
• : fs = 48/44.1 kHz
• Internal clock error: Within 60 seconds per month
• External dimensions: 220 mm (width) 44 mm (height) 270 mm (depth)
• Weight: DN-V750 : 2.0 kg (not including flash memory card) DN-V755 : 2.5 kg
• Power supply: AC adapter (SEA40N2-12.0) : Input AC 120230V, 50/60 Hz
• Power consumption: DC 12V 0.5A (DN-V750) / 1.0A (DN-V755)
Surrounding conditions • Operating temperature range : 5 to 40C (DN-V750) / 5 to 35C (DN-V755)
• Operating humidity range : 5 to 85%
• Storage temperature range : -20 to 60C (not including recording media)
• Storage humidity range : 5 to 90% (not including recording media)
