With a cool white 230 Watt, 8,500K > 79 LED engine, the Elation Platinum Spot LED III shines brightly, delivering a total of 7,200 lumens at its brightest. Get the effects you need with 16 to 32-degree motorized zoom and 8 dichroic colors. Expand your options even more on the Platinum Spot III, which utilizes interchangeable rotating glass, and 7 static-stamped metal gobos. The bi-directional animation wheel allows for variable speed, and the 3-facet rotating prism and frost filter give you the ultimate look. Save energy and heat with hibernation mode. The 3 pin and 5 pin DMX in and out connections allow you to connect to any DMX lighting situation. Motorized iris and focus, variable dimming curves, and high speed mechanical shutter and strobe are perfect for when you need ultimate control. The easy to read menu display is reversible, and the 6 button touch control panel puts the control at your finger tips. The Platinum Spot III is perfect for both TV and film, with flicker-free operation around-the-clock, and the multi-voltage switching power supply (100-240v) lets you bring this LED moving head anywhere.
Elation Platinum Spot III Features• Cool White LED Spot Luminaire
• 230W, 8,500K, >79CRI, 7,200 Lumen, 60,000 Hours
• 16 to 32 Motorized Zoom, 8 Dichroic Colors
• 7 Rotating-Interchangeable and 7 Static-Stamped Gobos
• Bi-Directional Variable Speed Animation Wheel
• 3-Facet Rotating Prism and Frost Filter
• High Speed Mechanical Shutter and Strobe
• Motorized Iris and Focus and Variable Dimming Curves
• Low Heat, Quiet Operation, Hibernation Mode
• Flicker Free Operation For Broadcast TV and FILM
Source• 230W Cool White LED Engine
• 60,000 Hour Average LED Life
Photometric Data• 8,500K, >79CRI, >7,200 Lumens
• 17,500 LUX 1,626 FC @8.2' (2.5m) (16 Full ON)
• 5,373 LUX 499 FC @8.2' (2.5m) (32 Full ON)
Effects• 16 - 32 Motorized Zoom
• Bi-Directional Variable Speed Animation Wheel
• 3-Facet Rotating Prism and Prism Macros
• Frost Filter Hybrid Wash Effect
• Motorized Zoom, Iris and Focus
• High Speed Mechanical Shutter and Strobe
• Variable Dimming Curves
Color• 8 Dichroic Colors
GOBOS• 7 Interchangeable-Rotating / Indexing Glass Gobos
• 7 Static-Stamped Metal Gobos
Control & Connections• (3) DMX Channel Modes (18 / 20 / 27)
• RDM (Remote Device Management)
• 6 Button Touch Control Panel
• Full Color 180 Reversible LCD Menu Display
• 8 / 16 Bit Resolution Adjustable Movement
• 3pin & 5pin DMX In/Out
Dimensions & Weight• Length: 14.8" (375mm)
• Width: 15.1" (384mm)
• Vertical Height: 23.7" (601mm)
• Weight: 46 lbs. (20.8 kg)
Electrical & Thermal• AC 100-240V - 50/60Hz
• 350W Max Power Consumption
• -13F to 113F (-25C to 45C)
Approvals• CE | RoHs Compliant | IP20
Elation Platinum Spot III Installation• Rigging: Clamps (Not Included)
• Working Position: Flat Surface / Inverted (180)
