Elation Protron Eclypse LED Strobe Light

FEATURES
• Versatile Color Blinder, Strobe, Wash Luminaire
• High Powered 1000W Air Cooled IPX4 Outdoor Rated
• 96 10W CREE RGBW 4-in-1 LEDs
• 31 Beam / 63 Field Angles
• 27,000+ Total Lumen Output
• Brilliant Eye Candy Effects
• Selectable Pixel Mapping Control Zones
• Strobe Intensity, Duration, Rate, and FX Control
• Super High Speed (1-25fps) Adjustable Strobe
• DMX, RDM, Kling-NET and Art-NET Protocol Support
• 8/16 Bit RGB and RGBW Smooth Color Mixing Modes
• Adjustable/Removable Yoke Bracket w/3-Position Holes
• Interlocking System for Multiple Unit Matrix Designs

SOURCE
• (96) 10W CREE 4-in-1 RGBW LEDs
• 15,000 Hour Average LED Life*
**LED Life may vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.

PHOTOMETRIC DATA
• 31 Beam / 63 Field Angles
• 27,000+ Total Lumen Output

EFFECTS
• Color Blinder, Strobe, and Wash
• Brilliant Eye Candy Effects
• Selectable Pixel Mapping Control Zones
• Strobe Intensity, Duration, Rate, and FX Control
• Super High Speed (1-25fps) Adjustable Strobe
• 8/16 Bit RGB and RGBW Smooth Color Mixing Modes

COLOR
RGBW

CONTROL / CONNECTIONS
• Multiple DMX Channel Modes (24 total channels)
• 4 Button Touch Control Panel with OLED Menu Display
• DMX, RDM, Kling-NET, and Art-NET Protocol Support
• IP65 3/5pin DMX and RJ45 ethernet In/Out
• IP65 Locking Power In/Out
• Fixture-to-Fixture Interlocking Alignment Pins/Locks

SIZE / WEIGHT
• Length: 24.9" (633mm)
• Width: 7.0" (177.5mm)
• Vertical Height: 14.4" (364.8mm)
• Weight: 34.6 lbs. (15.7kg)

ELECTRICAL / THERMAL
• AC 100-240V - 50/60Hz
• 843W Max Power Consumption
• 14F to 113F (-10C to 45C)
• BTU/hr (+/- 10%) 2874.63

APPROVALS / RATINGS
• CE | IPX4
