CONTROL FEATURES * USITT DMX-512 (16-bit resolution)* 21 DMX Channels* 4 Digit L.E.D. Display* On board menu settings* 3-pin XLR serial input/output* Sound active mode - built in mic. Lamp on/off Power con mains
OTHER FEATURES * Modular internal construction 1/4 turn removable lid 1/4 turn lamp replacement
OPTICAL SYSTEM * High output luminous- dichroic glass reflector* 14 - 32 degree linear Zoom All lenses are anti-reflection coated
COLORS * 2 Color Wheels* Color Wheel 1 - interchangeable color filters, 8 dichroic color filters + white, Split colors* Color Wheel 2 - interchangeable color filters, 8 dichroic color filters CTC, CTB + white, Split colors* Continuous, variable speed, color scrolling in both directions (rainbow effect)* More color combinations possible by overlaying the multi-color dichroic gobo and the colors on the color wheel
GOBOS * 3 gobo wheels* 23 Quick-Snap gobos system* 7 interchangeable, indexable, rotating gobos plus open 9 interchangeable, static gobos plus open 26.9mm outside diameter, 23mm image diameter, 3mm max thickness* Gobo Overlay (Gobo Morphing)
SHUTTER * Variable speed strobe effect (1-10) flashes per second* Pre-set variable/random strobe and dimming pulse effect
DIMMER * Dual Flag mechanical dimming system
IRIS * Beam narrow to wide (4% - 100%)* Variable speed iris macros* Small to large and large to small Iris Pulse Effect
FROST * Variable Frost Control* Hard edge to soft edge
PRISM * 3-facet rotating/Indexing Prism* Both directions at variable speeds* Macro-function for rotating gobos/rotating prism combinations
FOCUS * Motor driven focus from near to far
ZOOM * 14 - 32 degree linear Zoom
LAMP *Phillips MSR 700/2 (700W, 72V, 7500K, 1000 HRS) 55000 lumens, base: G22 (Medium Bi-Post)
PAN/TILT * Automatic Pan / Tilt position correction* Maximum PAN-movement 540 16-bit resolution Maximum TILT-movement 280 16-bit resolution
DIMENSIONS & WEIGHT * (LxWxH) 19" x 14" x 29" / 482.6 x 355.6 x 736.6 mm 63 lbs. / 28.5 kgs.
RIGGING * 2 X 1/4 Turn omega brackets 4 X M-10 threaded holes for clamps
POWER SUPPLY * Electronic Ballast* Voltage: AC 90-260V 50/60Hz * Power Consumption: 900W (120V=7.5A)
OPTIONAL ACCESSORY AVAILABLE SOON * CMY color mixing module w/ animation wheel
OPTIONAL DUAL ROAD CASE * DRC-700
