CONTROL FEATURES• RDMX Remote DMX Address• USITT DMX-512• 10 DMX Channels• 4 Digit L.E.D. Display• 3 pin XLR serial input/output• Sound active mode
OPTICAL SYSTEM• High output luminous-parabolic dichroic reflector• 19-degree Beam Angle• Optional Beam Angles• All lenses are anti-reflection coated
COLORS• 4 dichroic filters plus open• Split and shared color combinations• Continuous, variable speed, color scrolling in both directions (rainbow effect)• More color combinations possible by overlaying the multi-color dichroic gobo and the colors on the color wheel
SHUTTER/DIMMER• Variable speed strobe effect (1-10) Flashes per second• Pre-set variable/random strobe and dimming pulse effect• Dual Flag mechanical dimming system
PRISM• 3, 5, and 9 facet prisms rotating in both directions at variable speeds• Macro-function for rotating gobos/rotating prisim combinations
FOCUS• Motor driven remote focus from near to far
LAMPS• Phillips MSR 575/2 (575W, 7200K, 1000 Hrs.)
GOBOS• 2 gobo wheels, 13 total gobos, 10 metal, 3 glass• 6 interchangeable, indexable, rotating gobos plus open• 7 interchangeable, indexable, static gobos plus open• 26.9 mm outside diameter, 23mm image diameter• Gobo overlay
RIGGING• 1 x Heavy duty yoke• 1 x Safety cable hole
POWER SUPPLY• 8A or 4A Fuse• Magnetic Ballast• Voltage: AC 98, 120, 208, 220, 230, 240V 50/60zh• Power Consumption: 800W
DIMENSIONS & WEIGHT• 15"L x 11"W x 18"H• 61.5 lbs.
