• 15-inch LF SMX woofer
• 1.25-inch HF titanium compression driver
• 2000 W Class-D power amplifier with integrated FIR-Drive DSP
• 135 dB peak SPL
EV's FIR-Drive utilizes the latest Finite Impulse Response (FIR) filter technology to optimize transducer linearity. Advanced limiter algorithms for independent peak and thermal transducer protection.
Top Grade Components
State-of-the-art components deliver the legendary EV sound quality and reliability the pros trust: 2000 W Class-D power amplifiers with integrated DSP produce high SPLs utilizing high-sensitivity, low-distortion transducers (including DVX and SMX series woofers and 1.25-inch HF titanium compression drivers).
Complete full-function DSP control via a single-knob interface. LCD screen for easy system set-up and monitoring: location/application EQ presets, limiter status, input level controls/meters and master volume control to ensure optimal gain structure.
Lightweight, durable and compact 18-mm, 13-ply birch plywood enclosures finished with EVCoat. Eight mounting points for permanent installations. Custom die-cast aluminum pole cups, handles and hardware.
EV-patented Signal Synchronized Transducers (SST) waveguide design provides precise and consistent coverage across all system configurations. Waveguides are custom-designed and optimized per ETX Powered Loudspeaker model.
Built in the USA!
Designed, engineered, tested, and assembled for ultimate reliability by Electro-Voice in the USA.
Frequency Range40 Hz - 20 kHz
Maximum SPL135 dB peak dB
Power Consumption100 - 240 V, 50 - 60 Hz, 1.6 - 0.8 A
Power Rating2000 W
Frequency Response48 Hz - 20 kHz
Coverage (Nominal -6 dB) H90
Coverage (Nominal -6 dB) V60
LF TransducerSMX2150 380 mm (15 in)
HF TransducerDH3-B 1.25-in titanium compression driver
Crossover Frequency1500 Hz
Connector Type(2) XLR/TRS combo jack and (1) XLR link output
Enclosure Material18-mm, 13-ply birch plywood with EVCoat
Grill16AWG steel with powdercoat
Suspension(8) M10 suspension points
Height691 mm (27.2")
Width431 mm (16.97")
Depth447 mm (17.6")
Weight Net27.7 kg (61.07 lbs)
Shipping Weight31.5 kg (69.45 lbs)
