The black Electro-Voice EVID-S5.2T is a pair of 5.25" 2-way 70/100V commercial loudspeakers designed to provide full-range sound reproduction and even coverage for system designers, installers, and audio engineers configuring systems for paging and background and foreground music in stores, clubs, eateries, schools, and more. Each speaker is IP54-certified for weather-resistant use outdoors and features a fire-rated ABS plastic enclosure. A pre-assembled mounting system and supplied mounting hardware enable simple and efficient setup.
A removable, locking 4-pin Euroblock connector allows for compatibility with commercial amplifiers. The 5.25" woofer and 0.75" high-frequency driver yield a frequency response of 60 Hz to 20 kHz. With a 109 dB maximum SPL and a coverage area of 90 by 90, the EVID-S5.2T speakers deliver consistent audibility and even sound distribution.
• Pre-assembled mounting system allows 90 of horizontal rotation and 45 of vertical rotation
• 90 horizontal by 90 vertical coverage
• Fire-rated ABS plastic enclosure
• IP54-certified for enhanced weather resistance
• 5.25" long-throw woofer and 0.75" high-frequency driver
• 60 Hz to 20 kHz frequency response (-10 dB), 85 Hz to 20 kHz frequency response (-3 dB)
• 300W peak (75W continuous) power handling for 109 dB maximum SPL (115 dB peak)
• Removable, locking 4-pin Euroblock connector accepts up to 12 AWG (2.5mm) wire size
• Logo can be replaced to match speaker orientation
Frequency Range (-10 dB) 60 Hz 20 kkHz
Weight Net 7.05lbs (3.2kg)
Depth 5.94" (151mm)
Width 7.09" (180mm)
Height 10.04" (255mm)
Available Color Black or White
Connector Type Captive screws on wall bracket. Removable locking 4-pin connector (Euroblock) (2) for connection to additional speakers in a distributed line. Max. wire size 12AWG (2.5 mm)
Coverage (Nominal -6 dB) H 90
Coverage (Nominal -6 dB) V 90
Environmental Specs IP54 (per IEC-60529)
Frequency Response (-3 dB) 85 Hz 20Hz
HF Transducer 0.75 inch (20 mm)
LF Transducer 5.25 inch (133 mm)
Max. SPL/1m (calc) 109dB
Minimum Impedance 6O
Nominal Impedance 8O
Recommended High-Pass Frequency 60Hz
Sensitivity 1 W/1 m 90dB
Shipping Weight 17.42lbs (7.9kg)
Transformer 70V/100V (30W)
Weatherized Yes
