Galaxy Audio's CORE Series X amplifiers are the product of rigorous engineering and the latest advances in technology. The Class H power supply configuration utilizes four output transistors, a low voltage pair and a high voltage pair. Its low voltage transistors are active with any signal.
SPECIFICATIONS:• Class H amplifier
• SmartALIC gain management
100 watts @ 8 ohms (typically 146 watts @ 4 ohms)
• Frequency response: 200 Hz-20 kHz
• Total Harmonic Distortion: < 0.06 @ 8 ohms, < 0.1 @ 4 ohms
• EQ: Three band, center-detent controls
Input connections (with individual volume controls):
• One balanced "
• One balanced XLR (with +24 VDC phantom power)
• Output connections:
• One -inch speaker level
• One (post-EQ, post-level) RCA line out
• Indicator LEDs: Power, Compressor-Limiter
• One 5" driver with 40 oz. magnet structure
• Sensitivity: 98 dB @ 1 watt/1 meter
• SPLOWT: 9.12
• Fire retardant styrene with cast aluminum grille
• Built-In mic stand mount
• UL listed
• 6.75" x 10.94" x 6" (171 mm x 278 mm x 152 mm)
• 12.5 lbs. (5.7 kg)
