Now, all TRITON STUDIO Music Workstations have the CD-R/RW factory installed.
Take an Online Tour
For an online tour of the TRITON STUDIO, (including mp3 examples) click here.
Check Out the Flash DemoClick here to see the Triton Studio Flash Demo.
TRITON STUDIO 2.0 OverviewThe TRITON STUDIO OS Version 2.0 was introduced at the January, 2003 NAMM show. Check out the features that update offers.
Click here if you're setup for Streaming Video.To setup your system to see the video, click here.TRITON Studio IntroductionTRITON Studio was introduced at the Winter NAMM Show in January, 2002. The following video highlights the presentation from the event.
Click here if you're setup for Streaming Video.To setup your system to see the video, click here.MORE FEATURES:The TRITON STUDIO features Korg's HI (Hyper Integrated) synthesis system and best PCM sounds. Its high-capacity 48 Mbyte PCM ROM, with 429 multisamples and 417 drum samples, covers every need imaginable. And, in addition to the "classic" TRITON's complete ROM, the TRITON STUDIO also includes a new 16 Mbyte stereo acoustic piano with two levels of velocity switching. With room for up to seven PCM expansion boards and up to 96 Mbytes of sample RAM, you can expand the TRITON STUDIO to a whopping 256 Mbytes of waveform data.
The TRITON STUDIO delivers a staggering assortment of high-quality programs created by Korg's acclaimed voicing "team." Programs that range from piano, guitar, organ, synth and drums to the latest synth and sound effects. An amazing 1,536 Program locations are provided in user-writable memory (512 preloaded), as well as 256 sounds and 9 drum kits in ROM for GM2 compatibility. For drum Programs you can choose from 144 user drum kits (20 preloaded) and 9 ROM drum kits for GM2. User-writable memory also provides 1,536 Combination locations (512 preloaded), each of which allows you to use up to 8 timbres (8 sound programs) simultaneously. Open memory locations can be used for sounds that you edit/create, load from expansion board packages or get from other sources.
SPECIFICATIONS:Programs/Combos:• 1,536 user programs (512 preload)
• 128 programs for Korg\'s MOSS tone generator can be added (After installing the separately sold EXB-MOSS option)
• 144 user drum kits (20 preload)
• GM Level 2 - 256 programs + 9drum kits
• Tone Generator
HI synthesis system: • 48kHz Sampling frequency
• 48Mbyte PCM ROM
• 429 multisamples + 417 drum samples
• Sampling
• 16 bit
• 48 kHz stereo/mono sampling
• 16 Mbytes memory standard, expandable to 96 Mbytes
• Maximum of 1,000multisamples/4,000samples.
• Up to 128 indices can be assigned to a multisample.
• AIFF, WAVE, AKAI (S1000/S3000 samples and mapped multisamples) and Korg format sample data can be loaded. Note: TFD-1S - 4S not supported
Sound Source: • Single mode: 60 voices (60 oscillators) / Max 120 voices (120 oscillators)*
• Double Mode: 30 voices (60 oscillators) / Max 60 voices (120 oscillators)**
• Polyphony:
60 Oscillators to play PCM samples from the internal ROM bank or RAM (user sampling), and
60 oscillators to play PCM samples from the internal Piano bank or an EXB-PCM expansion board
Keyboard:• 61Keys/76Keys/88Keys (Real Weighted Hammer Action2)
• Velocity and aftertouch sensitive.
Effects: • Stereo digital multi-effect system.
• 2 master effects (mono in, stereo out),
5 insert effects (stereo in/out),and
1 master EQ (3 band stereo) simultaneously
• Number of effects
• 102 (insert effects/89 for master effects)
Sequencer:• Capacity and Functionality:
16 timbres, 16 tracks, 1/192 resolution,
150 preset/100 user patterns per song,
200 songs, 20 cue lists, 200,000 notes maximum,
Reads and writes Standard MIDI File (Format 0 and 1)
• RPPR:
Realtime Pattern Play / Recording,
One set per song,
74 patterns per
• Arpeggiator:
5 preset patterns
507 user patterns (3 X preload)
Controllers:Joystick,
• Ribbon controller:
(2) Assignable switches,
(4) Realtime knobs ,
(3) Arpeggiator control knobs
Control Inputs: • Damper pedal (responds to half-pedaling), Assignable (SWITCH/PEDAL)
Outputs: • Main = L/MONO, R,
• Individual = 1, 2, 3, 4,
• S/PDIF (optical 24 bits, 48/96 kHz),
Headphones
Inputs: • 1, 2,
• Level Switch LINE/MIC,
• Level volume,
• S/PDIF (optical 24 bits, 48/96 kHz)
Various:• MIDI: IN, OUT, THRU
Interface: SCSI
• Accessories: AC cord, Preload data disks TNSFD-00P
• Display: TouchView Graphical User Interface, 320 x 240 dots
• Power Consumption: 38 Watts
Disk Drive 3.5 inch 2HD/2DD, HDD (2.5 inch, 5 Gbyte)
Dimensions:• 61Keys = 43.46" (1104mm) Wide x 15.04" (382mm) Deep x 5.08" (129mm) High
• 88Keys= 58.07" (1475mm) Wide x 17.32" (440.5mm) Deep x 5.75" (146mm) High,
• 76Keys= 51.61" (1311mm) Wide x 15.04" (382mm) Deep x 5.08" (129mm) High,
Optional Accessories/Expansion:• EXB-PCM01: Pianos and Classic Keys PCM Expansion Board
• EXB-PCM02: Studio Essentials PCM Expansion Board
• EXBPCM03: Future Loop Construction PCM Expansion Board
• EXB-PCM04: Dance Extreme PCM Expansion Board
• EXB-PCM05: Vintage Archives PCM Expansion Board
• EXB-PCM06/07: Orchestral Collection PCM Expansion Board
