The Magnum1800 is a high-powered fogger suitable for any installation - from the largest to the smallest. Highly flexible, the 1800 is built sleek and rugged.
VIDEO
FEATURES: • Onboard DMX
• Internal remote control storage (
Missing Remote )
• Optional flying kit
• Continuous output
• 580 m/min fog output
• 1150 W (240V) / 1000 W (110V) heat exchanger
• 9 min heat-up time
• 3.8 liter fluid capacity
• Different fluid options for different applications
Physical
• Length: 500 mm (19.7 in.)
• Width: 232 mm (9.2 in.)
• Height: 266 mm (10.5 in.)
• Dry weight: 15.0 kg (33.1 lbs.)
Performance
• Max. fog output (approx.): 580 m3 per minute
• Max. operating time at full output (approx.): 90 minutes
• Operating time: Continuous, automatic level adjustment
• Warm-up time (approx.): 9 minutes
Control and Programming
• Control options: DMX
Construction
• Housing: Steel & aluminum
• Heat exchanger: 1150 W (240V) / 1000 W (110V), direct thermal protection
Fluid System
• Fluid pump: Oscillating piston, high pressure
• Onboard fluid capacity: 3.8 l
• Fluid consumption at peak output: 70 ml per minute
Installation
• Orientation: Floor or flown in optional hanging bracket
Connections
• DMX: 3-pin locking XLR
• Power cable entry: 3-pin IEC
