FEATURES:• 3 & 5 pin DMX interface
• Prepared for multifunctional digital remote
• RDM capable
• Floor standing or truss mounting
• Neutrik PowerCon connector
• 1200 m/min fog output
• Continuous output
• Tough and solid design
• 1800 W heat exchanger
• 7.5 min heat-up time
• Indirect Fluid Sensing System
• Proprietary Pro Steam Simulation fluid solution
• Different fluid options for different applications
• Leaves no oil residue on light fixtures
• Soft Start technology
Technical SpecsPhysical
• Length: 687 mm (27.1 in.)
• Length with optional drip tray: 752 mm (30.0 in.)
• Width: 379 mm (15.0 in.)
• Height: 248 mm (9.8 in.)
• Height with hanging bracket: 353 mm (13.9 in.)
• Weight, dry: 19.0 kg (41.9 lbs.)
• Weight, filled: 28.5 kg (62.9 lb.)
Performance
• Coverage volume: 1200 m3 (42,378 ft3) per minute
• Fluid consumption (maximum): 120 ml/minute
• Continuous effect output
• Ready time: 10 minutes
Control and Programming
• Control options: Integrated analog remote control, DMX, optional digital remote control, master/slave link mode
• Control parameters: Continuous or timer-controlled variable output
• Fog: Variable output control, 0-100%
• DMX channels: 1
• DMX compliance: USITT DMX512-A
• RDM compliance: ANSI/ESTA E1.20 RDM
Construction
• Color: Black, silver
• Housing: Steel and aluminum
• Fluid reservoir: 9.5 liter drop-in
• Hanging bracket: Integrated yoke with safety attachment point
• Heat exchanger: 1800 W, thermally protected
• Fluid pump: Oscillating piston, high pressure
• Fluid management: Fluid out sensing, sealed for transportation
• External fluid control: Fluid sensing
• Drip tray: Optional, bolt-on tray with reusable collection sponge
Installation
• Mounting: Standing or hanging
• Orientation: Up to +/- 45 from horizontal
• Clearance around machine: 100 mm (4 in.)
Connections
• AC power: Neutrik PowerCon
• DMX, link mode in/out: 3- and 5-pin locking XLR
• Remote control: 3-pin locking XLR
• Firmware: AVR socket
Electrical
• AC power: 220-240 V, 50/60 Hz
• Main fuse: 10 AT (slow blow), 250 V
• Typical power and current: 1890 W, 8.3 A*
* Measurements made at nominal voltage. Allow for a deviation of +/- 10%.Thermal
• Exterior surface temperature, steady state: 50 C (122 F)
• Maximum ambient temperature (Ta max.): 40 C (104 F)
• Max. nozzle temperature: 200 C (392 F)
• Minimum ambient temperature (Ta min.): 5 C (41 F)
Included Items
• Analog remote control: P/N 92765038
• Fluid reservoir 9.5 l: P/N 34300528
• Power input cable, EU, Neutrik powerCON, stripped ends, 2.5 m (8.2 ft.): P/N 11501041
