• Full HD 1080p (1920x1080) Resolution
• 4,000 ANSI Lumens
• 10,000:1 High Contrast Ratio
• 60" 196" Image Size (Diagonal)
• 1.151.49 Throw Ratio, 1.3x Zoom
• HDMI x 2, MHL Connectivity
• 10W Built-In Speaker
• 2D Keystone Correction
• Corner Fit Correction
Full HD 1080p and 3D SupportShowcase Full-HD and 3D content in sharp, 1080p definition and enjoy Blu-ray, video games, and HD broadcasting in beautiful, high-contrast quality without downscaling or compression.You'll appreciate uninterrupted viewing with no crosstalk thanks to DLP technology.
High ContrastA high contrast ratio ensures that text, images, graphs, charts and videos are projected with optimal clarity and enhanced sharpness, especially for numerical data. The MH741 is intended for demanding presenters who want their content to be clearly seen by every person in the audience.
MHL ConnectivityWith MHL you can present your business proposals and share your ideas instantly using your Android smart device. Turn small screen into big screen by mirroring documents, photos, videos, and any other content in your smart device onto the projection screen.
Built-in 10W Speaker PowerWith a powerful built-in 10W speaker, the MH741 delivers crisp, clear audio to fill even the largest rooms. Allowing your message to be clearly heard.
2D Keystone Correction2D Keystone correction provides installation flexibility by correcting the trapezoid effect via horizontal and vertical adjustments up to 30 degrees. With it, the projector can be placed off center, allowing the presenter to stand in front of the screen without blocking the image.
Corner Fit CorrectionCorner fit is a flexible and convenient way to align the picture perfectly by adjusting each corner of an image independently.
Closed CaptioningDisplay subtitles in video content without the need for an external closed-captioning device with the MH741.
Writing TemplatesNo matter the task at hand, BenQ makes presentations easier and the MH741 is no exception. Built-into the projector, there is a selection of three different line patterns, emulating the look of notebook paper to help make writing ad hock notes on whiteboards and blackboards a snap.
DisplayProjection System: DLP
Native Resolution: 1080p(1920x 1080)
Resolution Support: VGA(640 x 480) to WUXGA_RB(1920 x 1200)
Brightness (ANSI lumens): 4,000 Lumens
Contrast Ratio (FOFO): 10,000:1 ?
Display Color: 30 Bits (1,07 billion colors)
Native Aspect Ratio: Native 16:9 (5 aspect ratio selectable) ?
Light Source: Lamp
Light Source Wattage: 260W
Light Source life*:
Normal 2500 hours
Eco 3500 hours
SmartEco 4500 hours?
OpticalThrow Ratio: 1.15-1.49
Zoom Ratio: 1.3:1
Lens: F=2.592.87, f=16.8821.88?
Keystone Adjustment: 2D, Vertical & Horizontal 30 degrees
Projection Offset**: 115%(Full-Height)
Clear Image Size (Diagonal): 51"196"
Image Size: 30"300"
Horizontal Frequency: 15K - 102KHz?
Vertical Scan Rate: 24 - 120Hz ?
AudioSpeaker: 10W x1
InterfacePC (D-sub): 1
Monitor out (D-sub 15pin): 1
S-Video in (Mini DIN 4pin): 1
Composite Video in (RCA): 1
HDMI: 2 (1.4a one shared w/ MHL)
USB Type A: 1 (power supply, 5V, 1.5A)
USB Type Mini B: 1 (FW upgrade)
Audio in (3.5mm Mini Jack): 1
Audio L/R in (RCA): 1
Audio out (3.5mm Mini Jack): 1
Microphone in (Mini Jack): 1
RS232 (DB-9pin): 1
IR Receiver: 2(Front/Rear)
Security Bar: 1
CompatibilityHDTV Compatibility: 480i, 480p, 576i, 567p, 720p, 1080i, 1080p
Video Compatibility: NTSC, PAL, SECAM
Dimension and WeightDimensions (W x H x D)(mm): 314x102x216 mm
Net Weight (Kg/lbs): 3.3 kg
Accessories Included (Standard)Carton: Brown carton, hand carry type
Carry Bag: x 1
Remote Control w/ Battery: x 1
Power Cord (by region): x 1 (1.8m)
User Manual CD: x 1 (24L)
Quick Start Guide: x 1 (18L)
Warranty Card (by region): x 1
VGA(D-sub 15pin) Cable: x 1 (1.5m)
Lens cover: x1
