• Superb performance with low noise and smooth, transparent audio across the full audio spectrum and natural sounding selectable echo/reverb effects.
• Built-in DSP (Digital Sound Processor) for ECHO (REVERB) with 16 selectable preset level and echo intervals and separate Effects Send and individual channel Effects Return controls, and numeric LED display
• Input Trim controls on all channel inputs
• Peak LEDs on all input channels
• Pan pots on each mono channel and Balance pots on each stereo input
• 3 band EQ for all input channels
• Aux Send and Aux Return with Aux Send and Aux Return control
• Switch-able global 48V phantom power on mono channels
• Super accurate 10-segment LED display bar-graph meters
• High-quality sealed pots with center detents for all Pan/Balance and EQ controls
• Road-tough all steel construction. Rack ears included.
• 4 mono balanced XLR mic and unbalanced 1/4" line and 8 stereo unbalanced 1/4" inputs (12 total)
• Balanced 1/4" TRS and XLR Stereo Outputs
• 3 band EQ for all input channels, 7 band stereo graphic EQ for Master Mix
• 4 balanced 1/4" TRS inserts allow independent connection of effects devices for each mono channel
• 60 mm faders on all channels and master L/R and Effect bus mix for precise level control
• Switch-able 20dB pad on all channel inputs
• Tape level control for Tape In and Record Out • Separate Repeat control and separate effects • PFL monitoring for built-in DSP (Digital Sound Processor)
• Headphone output with separate volume adjustments.
• PFL control for each channel allows headphone monitoring independent of channel volume
• Erasable area above all faders for notations
• Internal shielded AC supply with 115V(60Hz)/230V(50Hz) select switch
• Dimensions & Weight: 16"x17"x 3.5" (406 x 432 x 89 mm), 14.7 lbs (6.7 Kg)
|Product Condition||New - On Clearance|
