• Construction: Body in black sheet steel with grey aluminium trim, with epoxy powder finish.
• Operating position: Horizontal.
• Power requirements: 220/240 Volts 50/60 Hz - Fuse 12A
• Absorption: 6A (built-in power factor correction)
• Lamps: 49.000 lumen - 750 h/life: HMI/GS 575W double ended - 6000 K & MSR 575W base GX 9,5 - 5600 K
• Lamp adjustment: The projector if fitted with lamp adjusters that allows control over lamp positioning.
• Optics group: Composed by a reflector, a temperated condenser lens, two high definition lenses with antireflective treatment.
• Ventilation: Forced via axial fan.
• Beam angle: 15 with standard iris (diam. 55 mm), at 15 mt distance 450 cm diam. beam
• Douser: Mechanical device for reducing beam power to complete blackout if necessary. Available as accessory (code W1167)SEE BOTTOM OF PAGE
• Colourchanger: Built-in with 6 different colored gel + black out.
• Elapsed time meter: For checking operating time since the last check-up in a specialized centre.
Two microswitches automatically cut off the luminaire's power supply if the top panel is removed It has a manual reset thermal circuit breaker that trips when an operating temperature of 90 is exceeded Built-in power factor correction system. All metal parts are grounded. o Manufactured in compliance with CE norms. Protection against external agents: to IP20 Dimensions: With bracket: 98 x 44 x 45 cm. 25kg - 55lb
