FEATURES:• Display: Digital Light Processing DLP' Technology Texas Instruments
• Resolution: Native XGA (1,024 x 768), SXGA (1,280 x 1,024) compressed
• Computer Compatibility: IBM PC and • Compatibles, Apple Macintosh, iMac, NEC PC98 Series, Fujitsu FM Towns, and VESA Standards
• SXGA, XGA, SVGA, VGA (resizing)
• Video Compatibility: Full NTSC, NTSC4.43, PAL, PAL-M, PAL-N, SECAM and HDTV (480i/p, 576i/p, 720p, 1080i)
• Aspect Ratio: 4:3 Native, 5:4 / 16:9 Compatible
• Contrast Ratio (Typical): 600:1
• Displayable Colors: 16.7Million colors
• Brightness (Typical): 1,600 ANSI Lumens
• Projection Lens: F / 2.44 2.69, f = 28.8 34.5 mm
• 1:1.2 Manual Zoom and Manual Focus
• Throw Ratio: 2.0 - 2.4
• Projection Screen Size (Diagonal): 23.4" (0.594m)295" (7.5m)
• Projection Distance: 3.7' (1.14m) 39.4' (12m)
Horizontal Scan Rate: 15 100 kHz
• Vertical Refresh Scan Rate: 43 120 Hz
• Lamp Type: 200 W User Replaceable UHP Lamp
• Lamp Life: 2,000 Hours
• Keystone Correction: +/-16 degree
• Audio: 2 Internal Speakers Each with 3 watts Output
• Weight: 6.4 lbs (2.9 kgs)
• Dimension: 10.9 x 8.9 x 3.3 inches, 277 x 225 x 85 mm
• Remote Mouse Control: Remote Control with • Mouse Function & Laser Pointer
• Power Supply: AC input 100 - 240 V
• Input Frequency: 50 - 60 Hz with PFC Power Supply
• Power Consumption: . 320 W in Normal Operation
. Standby mode < 2 watts
• Operation Temperature: 0oC 40oC / 32oF 104oF
• Noise Level (Typical): 32 dB in Normal Operation
• Uniformity: 90%
• I/O Connectors:
• PC I/O: Input:
. 1 HDB 15-Pin D-Sub (Component Video/HDTV input port)
. 1 DVI Connector
. 1 Audio Mini Jack (for 15-pin D-SUB)
. 1 Audio Mini Jack (for DVI)
Output:
. 1 Mini D-SUB 15-Pin for Monitor Loop Through
• VIDEO I/O: Input:
. 1 Mini DIN for S-Video Input Connector
. 1 RCA Jack for Composite Video Input Connector
. 1 RCA Audio Inputs
Output:
. 1 Mini Din Audio Output for VGA/Video
• Remote Mouse I/O: 1 Remote Mouse Port
• Communication Port: RS-232
