There is no easier or smarter way to biamp your system than with the SAC 22 Crossover. The Mono Sub Output provides a separate mono sum of the Left and Right Low Outputs. A 100 Hz low pass filter may be activated for this Output. The Subwoofer Output may be used along with the Left and Right Low Outputs.
The SAC 22 employs state-variable 4th-order Linkwitz-Riley filter alignments to minimize phase difficulties in the critical crossover region. Simply put, a Linkwitz-Riley crossover exhibits identical phase characteristics on its Low pass and High pass Outputs. This characteristic guarantees in-phase outputs at all frequencies. In-phase outputs are mandatory for proper acoustic summing of common signals from adjacent drivers in the crossover region. An added benefit of this topology is steep 24 dB per octave rolloff slopes. A slope of this magnitude guarantees drivers designed to produce a specific range of frequencies, and no more, will not be driven past their limits, thereby minimizing distortion and driver fatigue.
The SAC 22 utilizes a 31-position precision DC control voltage potentiometer to select the Low/High Frequency point. This crossover circuit design assures consistent accuracy from channel-to-channel and unit-to-unit. This is a distinct advantage over continuously variable designs using ganged potentiometers which can yield large variations in channel-to-channel matching.
The Input Level allows decreasing the overall sensitivity of the entire sound system, including the mono subwoofer if one is used. The Low Level, High Level and Mono Subwoofer Output Level controls allow compensation for sensitivity variations in amplifiers and drivers.
* Precise Channel Matching with Single Set of Controls.
* 31 Position Frequency Selector.
* High and Low Output Level Controls.
* +4 dBu and Overload Indicators.
* 24 dB/Octave Linkwitz-Riley Filters.
* Separate Mono Sub Woofer Output
* Balanced XLR Connectors
* Internal AC Power Supply Meets CE Requirements.
|SKU||SAC 22 NEW|
|Product Condition||New - On Clearance|
