Active speakers for live sound reinforcement and stage monitoring as well as distributed sound systems for clubs, music venues and corporate events. ART 315-A MK4 is the ideal speaker when an exceptional full range, outstanding bass reproduction and accurate high frequency delivery are required.
• 129 dB Max SPL
• 800 WATT 2-way peak power
• DSP Processing with FiRPHASE
• 15" Woofer, high powered 2.5" voice coil
• 1" HF driver, mylar dome, 1.5" voice coil
NEW PERSPECTIVE ON LINEARITYRCF speakers are designed using a proprietary and advanced FiR filtering technology, conceived to deliver transparent sound, absolute clarity and perfect stereo images to the listener. The special FiRPHASE filters allow to achieve coherent distribution of sound for all listeners without phase distortions, ensuring minimum latencies to the system.
SUPERIOR TRANSDUCERSWoofers and compression drivers are precision built taking advantage of RCF's technologies and a wealth of professional knowledge and experience dedicated to achieving extremely high standards.
POWERFUL CLASS D AMPLIFIERSRCF's Class-D power amplifier technology packs huge performance operating with high efficiency into a lightweight solution. ART 3 amplifiers deliver ultra-fast attack, realistic transient response and impressive audio performance. The amplifier features a solid mechanical aluminium structure which not only stabilises the amplifier during transportation but also helps the fan-less heat dissipation. All the ART 3 amplifiers present SMPS power supply section in order to produce maximum output and minimum transportation weight.
BRING ART WITH YOUEvery ART model can be used in the standard or stage monitor configuration
Thanks to the rear profile of the cabinet, the ART 3 Series speakers can easily be used as stage monitors whatever the needs of musicians. Internal reinforcement prevents any deformation of the cabinet.
ART 3 speakers are ideal for the musician or sound provider. Their plug n' go design is simple yet powerful: double input (XLR or Jack), one volume knob. Cabinets are moulded on a special polypropylene composite material designed to dampen down vibrations even at maximum volume settings. From moulding to the final texture, ART3 offers maximum reliability and strength for intensive use. The ART 3 MK4 are equipped with handles for greater portability.
Specifications
Frequency Response: 45 Hz 20000 Hz
Max SPL @ 1m: 129 dB
Horizontal coverage angle: 90
Vertical coverage angle: 60
Compression Driver: 1.0'', 1.5'' v.c
Woofer: 15'', 2.5'' v.c
Input signal: bal/unbal
Input connectors: XLR, Jack
Output connectors: XLR
Input sensitivity: -2 dBu/+4 dBu
Mic. Input Sensitivity: -32 dBu
Crossover frequencies: 1800 Hz
Protections: Thermal, RMS
Limiter: Soft Limiter
Controls: Volume, Boost, Mic/Line
Total Power: 800 W Peak, 400 W RMS
High frequencies: 200 W Peak, 100 W RMS
Low frequencies: 600 W Peak, 300 W RMS
Cooling: Convection
Connections: VDE
CE marking: Yes
Cabinet/Case Material: PP Composite
Hardware: 4 x M10
Handles: 1 Top, 2 Side
Pole mount/Cap: Yes
Grille: Steel
Color: Black
Height: 680 mm / 26.77 inches
Width: 405 mm / 15.94 inches
Depth: 345 mm / 13.58 inches
Weight: 17.1 kg / 37.7 lbs
