The Diversity Fin Antenna is the flagship RF Venue wireless microphone antenna Matte black paint with L-bracket wallmount and install hardware.
RF Venue DFINB Features:• Frequency Range: 470 - 698 MHz
• Architect-friendly (unmarked) matte Black Paint - No logos or markings on unit
• Includes L-bracket and easy hardware for wall mounting
• Does
NOT include protective cover
• Mounting block accepts 5/8-27, 1/4-20, AND 3/8-16 stands
RF Venue DFINB Electrical Characteristics:• Operating frequency: 468-740 MHz
• Bandwidth: 272 MHz
• Average return loss: -9.4 dBm
• Impedance: 50 ohms
• Pattern type: Dual Omni-Unidirectional
LPDA:• Beam width: 140 Azimuth
• F/B Ratio: 8 dB
• F/S Ratio: 5 dB
• Gain: 5 dBd
• Polarization: Vertical
Dipole:• Beam width: 100 Azimuth
• F/B Ratio: 5 dB
• F/S Ratio: 13 dB
• Gain: 1.8 dBd
• Polarization: Horizontal
RF Venue DFINB Physical Characteristics:• Dimensions: 12" L x 15" H (300 x 370 mm)
• Weight: 1 lb (454 g)
• Mounting Block: 1/4-20, 3/18-16, 5/8-27 ??
• Operating temperature: -10 - 130 F (-23 - 54 C)
• Color: Black
• Connector: BNC female (2)
