FEATURES:• 4x4 velocity sensitive pads for intuitive rhythm programming and phrase audio operation
• Enhanced effects, including Isolator, Filter + Drive, Slicer, Reverb, Tape Echo and onboard
Mastering capabilities
• Unique control over performance and playback via Roland's
• Beam controller and V-LINK function*
• A CompactFlash slot for storing audio samples (in the SP-606's Pad Bank format) and import/export of WAV/AIFF files
• USB connection allows MIDI data/Bulk Dump and audio streaming storage capabilities
• Increased storage and download capabilities,
including CompactFlash cards (with up to
512MB capacity) and USB jack
• 4-track sequencer with up to 18,000 note
capacity, MIDI sequencing and BPM sync
for audio phrase time stretching
• S/PDIF I/O for high-quality recording and
track making with digital equipments
• Bundled with new P606 software from Cakewalk for enhanced integration and
functionality with a PC via USB
SPECIFICATIONS:• Maximum Polyphony 8 voices
• Sampling Mode Standard/Long n Sampling
Frequency 44.1 kHz n Data Format SP-606 original format (WAV/AIFF import/export
possible)
• Internal Memory Samples: 128 (8 Banks) *Including Pre-loaded Sample Banks
• Card Memory Sample: 384 (24 Banks) n Effects Section Multi-Effects: 2 systems, 45 types, Mastering Effect: 2-bands Compressor • Sequencer Section Mode: Pattern, Song,
Tracks: 4, Resolution: 96 ticks per quarter note, Song Steps: 999, Songs: 25, Patterns: 140
*Including Pre-loaded Patterns, Maximum measures per Pattern: 32, Beats: 2/4-32/4,
Tempo: 40.0-200.0, Pattern recording method: Realtime, Step Recording (Note/Sample),
Maximum recordable notes: Approximately 18,000 notes, (Approx. 8,000 per Pattern)
• Others
Display: 128 x 64 dots (Backlit graphic LCD), Controllers: Control Knobs x 3, D Beam,
Pads:16 with velocity sensitivity, Connectors: Headphones Jack, Output Jacks (L (Mono), R), Input: Jacks (L (Mono)/Mic, R), Foot Switch Jack, Digital Audio Interfaces (Coaxial, In/Out), MIDI
Connectors (In, Out), USB Connector (compatible with MIDI, Audio, and mass storage class),
AC Adaptor Jack
• Power Supply: DC 9 V (AC Adaptor) n Current Draw 1,000 mA
• Dimensions: 358.3 (W) x 271.2 (D) x 84.0 (H) mm, 14-1/8 (W) x 10-11/16 (D) x 3-5/16 (H)
inches
• Accessories: Owner's Manual,
AC Adaptor (ACI Series or PSB-1U), USB Cable, CD-ROM (USB MIDI/Audio driver, P606),
Card theft prevention cover n Options Pedal Switch (DP-2), Foot Switch (BOSS FS-5U)
