Widely used in installed sound and live music situations, LX Wireless systems deliver top-notch performance and VHF reliability at a moderate price. They enable users to configure a wireless system, with a wide array of professional handheld, lavalier, instrument and headworn microphone options as well as single-antenna or diversity receivers.
• WCM16 Headset Mic.
• LX1 Bodypack Transmitter.
• LX4 Diversity Receiver.
WCM16 Headset Mic:
The Shure Model WCM16 headworn electret condenser microphone is intended for wireless use by performers, lecturers, and others who require the highest quality voice pickup with maximum mobility. Its wide frequency response, low RF susceptibility and reliable operation at temperature and humidity extremes make the WCM16 suitable for virtually any vocal application. When used with the Shure Body-Pack Transmitters, the performance of the WCM16 closely resembles the finest conventional vocal microphones.
Miniaturized active circuitry included in the cartridge assembly provides equalization that tailors the low-frequency response to resemble the warmproximity effect of larger vocal microphones. Because of this low-end response, it is not necessary to position the microphone directly in front of the mouth, thus avoiding much popping and breath noise, even without the supplied foam pop screen.
The microphone's hypercardioid unidirectional pickup pattern provides maximum isolation from ambient noise and from adjacent sound sources such as musical instruments, loudspeakers and other performers. This permits higher gain-before-feedback without loss or masking of vocals.
• Extra lightweight, adjustable headband stays secure and virtually disappears while being worn.
• Response comparable to finest conventional vocal microphones.
• Hypercardioid polar pattern provides maximum isolation from vocalist's own instrument and those of other performers.
• Uniform polar pattern at all frequencies for maximum gain before feedback.
• High input clipping level eliminates overload distortion.
• Cable terminates as 4-pin mini connector.
• Supplied acoustic foam pop screen.
• Reliable at temperature and humidity extremes.
LX1 Bodypack Transmitter:
The low-profile, highly durable body-pack LX1 has all the characteristics to meet the demands of high performance.
• 18-20 hour battery life.
• Three-segment, LED power/battery fuel gauge.
• Adjustable audio gain control.
• Guitar system compatibility.
• 4-pin mini connector.
• 9V battery included.
LX4 Diversity Receiver:
The Shure LX4 receiver offers our exclusive Shure MARCAD Circuitry. MARCAD (MAximum Ratio Combining Audio Diversity) circuitry constantly monitors signals from both receiver sections and combines them to create a single output signal. The result is improved reception and exceptional freedom from dropouts.
• Five-segment, audio-level meter.
• Five-segment, RF-level meters for A and B antennas.
• Noise-sensing squelch control.
• Mic/line level switch .
• PS40, PS40E, PS40J or PS40UK in-line power supply with locking DC connector .
• All metal chassis.
• Space-saving, 1/2 rack design.
• Single and dual rack mounting hardware included.
|SKU||LX14- WCM16 AD|
|Product Condition||New - On Clearance|
Shure LX14 Wireless Headworn Mic System, Wcm16 Ad Reviews
