For example, the AV-452 main unit can learn IR commands for a projector or TV. Whenever an A/V source is selected on the AV-452, the IR code for that input can be sent to the TV or projector, thereby ensuring the proper video source is being shown. In addition, a learning universal remote is included, centralizing control over the AV-452 and up to four components.
For A/V installers, the AV-452 offers numerous options to control and customize the box. The AV-452 can integrate with building alarm systems and accept constant voltage speaker signals. Plus, there are two alternatives for creating external control functionality: buttons and LEDs can be attached to the AV-452's Relay Control port, or the AV-452's serial control port can link with a control system for bi-directional control.
The AV-452 is well equipped for a variety of environments, as outlined in some examples below.
• (4) Microphone Channels w/ Phantom Power
60mm Fader, Gain, Mute and 3-band EQ Controls.
• A/V Channel Strip w/ Video Switching
Inputs for (2) Audio Sources and (3) Audio/Video Sources.
60mm Fader, Gain, Dim and 3-band EQ Controls.
Record Monitor Control for Dubbing Between Sources.
• Motorized Room Volume Control.
• Built-in Digital Power Amp
100W/side @ 8 Ohms, operates from 4-16 Ohms.
• Headphone Output w/ Level Control.
100mW/side @ 68 Ohms, 1/4" TRS Connector.
• Universal Learning Remote Included.
Buttons for AV-452, Projector Power and A/V Components.
• Built-In Projector Switching Control Capability
AV-452 Unit Learns IR Codes to be Transmitted to Projector.
• Bi-Directional Control Integration Capability
Relay Control Port for Direct Connection of Buttons and LEDs.
Serial Control Port for RS-232/422/485 Control Protocols.
• Integrates w/ Building Communication Systems.
12V/24V/70V Constant Voltage Input w/ Mute and Gate.
EMG Input Mutes AV-452 When Emergency Alarm is Detected.
• Room for Growth & Enhanced Operation.
Balanced Line Output for Using External Amplifiers.
Balanced Cascade Input for Adding Submixers or Linking Rooms.
Mic Group Insert for Dynamic Processing or Splitting signals.
Meeting Record Output for Documenting Meeting Minutes.
|Product Condition||New - On Clearance|
