Tascam CD-BT2 Bass Trainer and Portable CD Player

With its ultra-compact design and new functionality, the new CD-BT2 trainer from TASCAM is the most user-friendly trainer ever. The new CD-BT2 bass trainer completes our all-new lineup of trainers for the musician, student, teacher and artist on the go.

The new CD-BT2 bass trainer features an all new improved ultra compact design, comprehensive LCD display with graphical user interface, Album title/Track title indication by CD-Text, expanded effect banks for user preset, chromatic tuner, and TASCAM'S pioneering VSA (Variable Speed Audition, pitch control without affecting key) feature lets music fans learn up a continuous mix of their favorite songs anywhere they go.

With TASCAM'S legendary ease of use, pioneering features such as integrated pitch and key control, bass canceller with selectable canceling pan point and selectable frequency range, and seamless integration with CD-DA/CD-R/CD-RW disc playback. Users can now discover the licks their favorite artist really played.

FEATURES:
• Portable CD bass trainer (More compact than previous CD-BT1MKII)
• CD-DA/CD-R/CD-RW disc playback
• 10 second anti-shock memory
• Comprehensive 128 x 64 dot matrix LCD display with graphical user interface
• Album title/Track title indication by CD-Text
• Elapsed Time/Remain Time display with bar meter
• +16 to -50% pitch control in 1% steps
• VSA (Variable Speed Audition, pitch control without affecting key)
• Key control: +/-6 semi-tone, in semi-tone steps with +/-50 cents fine tune
• Single play and continuous play
• Single Loop, All Loop, and Seamless IN-OUT Loop
• Flash Back function (Instant review up to 5 seconds prior playback)
• Bass Canceller with selectable canceling pan point and selectable frequency range
• 10 effect banks for user preset
• Chromatic tuner with calibration (435 to 445Hz)
• 3 octaves tone oscillator
• Metronome (BPM: 40 to 220, Beat: 2 to 6)
• 1/4" Bass input
• Bass/Mic input volume
• Bass/Mic input level meter indicator on LCD display
• CD level meter indicator
• Foot switch connector
• 5 selectable functions by foot switch (Flash Back, Rewind, FF, Bank, Effect on/off)
• 1/8" stereo line output
• 1/8" stereo headphone output
• Headphone volume
• MONO monitor for CD (L+R, L, R)
• Split monitor (Left ch: CD, Right ch: Input or vice versa)
• Battery operation
• Optional power supply PS-P520

SPECIFICATIONS:
• Disc Type: 8cm and 12cm CD
• Line Output Connector: 1/8" Stereo mini connector
• Nominal Stereo Output Level: -10dBV
• Output Impedance: 600ohm (2V RMS)
• Maximum Output Level (LINE OUT): +6dBV
• Headphone Output Connector: 1/8" Stereo mini connector
• Maximum Output Level (PHONES): 15mW (at 32ohm loaded)
• Bass/Mic Input Connector: 1/4" Phone Connector
• Nominal Input Level
• Bass Input: -15dBV
• Mic Input: -40dBV
• Maximum Input Level
• Bass Input: +6dBV
• Mic Input: -19dBV
• Frequency Response: 20 Hz to 20 kHz (-3/+1dB) - (A weight filter + 20KHz LPF)
• Signal to Noise Ratio: Better than 85 dB
• Total Harmonic Distortion: < 0.03% (200Hz HPF + 20KHzLPF)
• Channel Separation: Better than 80dB - (A weight filter + 20KHz LPF)
• Power Requirements: DC 5V (Optional AC adapter PS-P520), AA batteries x 4
• Power Consumption: 4W (with PS-P520)
• Dimensions (W x H x D): 194 x 38.7 x 138(mm)
• Weight (excluding batteries): 550g
