Five BR models are designed to fit the budgets of performing musicians, small churches, and schools while delivering the full-frequency response and high output of more costly systems.
Built Right...Combining our knowledge of acoustics and advanced computer controlled woodworking, Yamaha Music Manufacturing in Thomaston, Georgia, crafts the BR line of sound reinforcement loudspeakers.
This world class, environmentally friendly, ISO 14001- registered facility carefully assembles each cabinet to exacting tolerances. Each model's large steel handle(s), corner protectors, and built-in pole socket assure both durability and flexibility.
Steel corner protectors keep your cabinets free from dings and damage associated with frequent transport.
Large metal handles mounted at each cabinet's center of gravity make them very easy to carry.
All models, including the monitors, come with stand/pole sockets for flexibilty of use.
Better Response...BR cabinets are carefully designed for the best balance of small, easy to handle size and great low-frequency response, using Bass Reflex technology. High-frequency response is also enhanced with a new titanium HF driver and 90 by 40 non-resonant horn.
Best Reliability...With integral protection circuitry built into the passive crossover, you can expect a long life of high output and minimal distortion.
TECHNICAL SPECIFICATIONS:* Tweeter (diaphragm): 1" Titanium
* Frequency Response(-10dB): 65Hz-20kHz
* Power Handling (noise*/program/peak)
* EIA RS426 :200/400/800W
* Nominal Impedance: 8 ohms
* Sensitivity 1W, 1m: 98dB
* Input Connectors: 2 X 1/4" Phone
* Dimensions W x H x D(approximate): 19" x 25 3/4" x 14 1/2"
