TECHNICAL SPECIFICATIONS:• Fusion Engine Synthesis - Sample Playback, Virtual Analog, FM, Physical Modeling
• Polyphony: Dynamic processor allocation. Up to 180 voices of sample
playback.
• Multitimbral Capacity: Mix: 8 internal/16 external, Song: 16 internal/16 external
• Waveforms- tones 120 MB (when converted to 16-bit linear format)
• Sounds:
Preset Instruments: 800 Programs
Preset Drumkits : 64 Drumkits
GM: 128 Programs, plus 8 Drum Kits
User: 40GB of whatever you want
• Mixes: 200 Mixes
• Filters: 13 types
• Effects- types and amt
• 20 Reverbs, 10 Chorus, 50 Insert Effects, 4 Band EQ (low shelf, low, mid, high mid, Hi shelve
Sampler: • Multi-samples (waveform capacity):
128 samples per Multisample
• Sampling sources:
Analog Input L/R, Stereo Output (resampling)
• A/D Conversion: 24 -bit, 64 X oversampling
• D/A Conversion: 24 -bit, 128 X oversampling
• Sampling Frequencies: 44.1 kHz
• Memory: Memory 64MB installed, optional expansion to 192MB
• Sampling Time: 11 Min, 53 Sec (with onboard memory), 37 Min, 15 Sec (with full expansion memory)
• Sample Formats: Alesis format, wav
Sequencer:• Note Capacity: Unlimited / based on HD limitations
• Note Resolution: 480 ppq
• Tracks: 32 Tracks
• Songs: 40GB of whatever you want
• Arpeggio
Preset: Preset 1000
User:User Unlimited
• Sequence Format: SMF
• Controllers:
Pitch Bend Wheel, Modulation Wheel, Aftertouch, Assignable Control Knobs (4), Assignable Trigger Buttons (4), Assignable Switches (2)
• Display: 240 x 128 backlit LCD
• External Storage: Compact Flash Type I and Type II (Flash and Microdrives), SATA HD and (by Fall 2005) CD-RW
• Connectors:
Stereo Input L-Mono/R (Standard 1/4 Jack), Stereo Headphone Output (Standard 1/4 Jack),Stereo Main Output L/R (Standard 1/4 Jack), Stereo Aux Output L/R (Standard 1/4 Jack), S/PDIF Output (Coax/Optical), ADAT Output (Optical), MIDI In/Out/Thru, Sustain Pedal, Footswitch, Expression Pedal, USB (to Host), HD Recording Inputs 1-8 (Standard 1/4 Jack), External Drive (SATA), AC Inlet
• Power Consumption: 50 W
• Dimensions:
Fusion 8HD: 51.5x14x5 in, 130.8x35.6x12.7cm
Fusion 6HD: 35.5x14x4 in, 90.2x35.6x10.2 cm
• Weight:
Fusion 8HD: 58.4 lb, 25.6 kg
Fusion 6HD: 30.4 lb, 13.8 kg
