ChamSys MagicQ MQ80 Compact Lighting Console

MagicQ MQ80 features the same software found on all MagicQ consoles, and uses the same show file formats, enabling compatibility between all MagicQ products. MagicQ MQ80 can be connected over network to a PC or Mac running the free ChamSys free MagicVis lighting visualisation software, or MagicHD media player software (for output of up to 8 layers of HD media) at no extra cost.

The construction of the MagicQ MQ80 incorporates high reliability components, including durable metal Neutrik locking connectors. The inbuilt 4 port Ethernet switch is protected by the UPS, thus ensuring that both the console and the network switch maintain operation even during a power loss.

The console features a Kensington security slot for securing the product. Both soft bags and flight cases are available as optional extras.



Features:
• 48 universes direct from the console
• Fits within checked luggage
• 10 Playback faders, 200 Pages
• 20 Execute buttons
• UPS inbuilt to the console
• External monitor (full HD, can be touch)
• Includes MIDI, Audio and Timecode input support
• RDM support via direct DMX Ports and Network

MagicQ Software
MagicQ software offers powerful lighting control with loads of features that lighting designers have some to rely on, such as full lighting visualisation, pixel mapping, and HD media playback on up to 8 different layers, all integrated smoothly to streamline workflows, save time, and shorten learning curve.

Training Courses & Videos

Universes supported: 48*
Channels: 24576
Number of fixtures: Up to 24576
Cues: 5000
Groups: 5000
Display: 12"
Touch Screen: Multi touch
DMX 5-Pin XLR: 4
RDM Support: Yes
Faders: 12
Attribute encoders: 8
Network ports: 4
USB ports: 6 (including 1 on front panel for easy access)
Audio in: Yes
Audio out: Yes
MIDI: Notes, TC, Show Control
LTC in/out: Yes
Remote input port: Yes
Wing Support: Yes
Multi console: Yes
1 Dual Colour Dimmable LED Console Lamp
Power input: 110 to 240 VAC
UPS: Yes
Width: 570mm (22.5")
Depth: 405mm (15.9")
Height: 110mm (4.3")
Weight: 8kg (17.5lb)

*Originally 24 universes - increased to 48 from software version 1.8.4.5.
